Grizzly G1014Z Owner's Manual page 57

REF PART # DESCRIPTION
1 P1014Z001 DUST COVER
2 P1014Z002 EXT RETAINING RING 12MM
3 P1014Z003 BALL BEARING 6201-2RS
4 P1014Z004 DRIVER ROLLER SHAFT
5 P1014Z005 SANDING BELT 6'' X 48'' A60 (2-PC)
6 P1014Z006 KEY 5 X 5 X 55
7 P1014Z007 EXT RETAINING RING 15MM
8 P1014Z008 SANDING BELT FRAME
9 P1014Z009 BACK STOP
10 P1014Z010 SET SCREW 5/16-18 X 3/8
11 P1014Z011 DRIVE ROLLER
12 P1014Z012 HEX NUT 5/16-18
13 P1014Z013 FLAT WASHER 5/16
14 P1014Z014 KNOB 5/16-18
15 P1014Z015 BALL BEARING 6202-2RS W/SNAP RING
16A P1014Z016A COMPLETE MITER GAUGE ASSY
17 P1014Z017 BUSHING 15 X 19.4 X 12MM
18 P1014Z018 CARRIAGE BOLT 5/16-18 X 1-1/2
19 P1014Z019 PULLEY COVER W/DUST PORT V2.07.00
20 P1014Z020 MITER BAR
21 P1014Z021 CAST IRON DISC V2.02.97
22 P1014Z022 SANDING DISC 9" A60 PSA (2-PC)
23 P1014Z023 TABLE
24 P1014Z024 TRUNNION
25 P1014Z025 FLAT WASHER 1/4
26 P1014Z026 PHLP HD SCR 1/4-20 X 1/2
27 P1014Z027 PHLP HD SCR 10-24 X 3/8
27A P1014Z027A FLANGE SCREW 10-24 X 3/8
28 P1014Z028 MITER GAUGE POINTER
29 P1014Z029 TABLE SUPPORT BRACKET V2.01.98
30 P1014Z030 SUPPORT BAR
32 P1014Z032 HEX BOLT 5/16-18 X 1/2
33 P1014Z033 TABLE MOUNT L & R (2 PC SET)
34 P1014Z034 V-BELT M24 3L240
35 P1014Z035 PULLEY
36 P1014Z036 MOTOR PULLEY
37 P1014Z037 KNOB 10-24
39 P1014Z039 HEX BOLT 5/16-18 X 1
40 P1014Z040 BRACKET
41 P1014Z041 HEX BOLT 5/16-18 X 1
42 P1014Z042 SET SCREW 5/16-18 X 3/8
43 P1014Z043 MOTOR 3/4HP 110V/220V 1-PH
43-1 P1014Z043-1 CENTRIFUGAL SWITCH
43-2 P1014Z043-2 MOTOR FAN
43-3 P1014Z043-3 MOTOR FAN COVER
43-4 P1014Z043-4 S CAPACITOR 200M 125V 1-3/8 X 2-1/4
43-5 P1014Z043-5 S CAPACITOR COVER
43-6 P1014Z043-6 JUNCTION BOX COVER
44 P1014Z044 KNOB BOLT 1/4-20 X 3/4
45 P1014Z045 PLASTIC WASHER 1/4-16
46 P1014Z046 FLAT WASHER #10
49 P1014Z049 STRAIN RELIEF M14 TYPE-1 SNAP-IN
50 P1014Z050 SWITCH PLATE
Model G1014Z/G1014ZX (Mfd. Since 08/22)
G1014Z Main Parts List
REF PART # DESCRIPTION
51 P1014Z051 HEX NUT 10-24
52 P1014Z052 BASE
53A P1014Z053A SAFETY PADDLE SWITCH
56 P1014Z056 HEX NUT 5/8-11
57 P1014Z057 HEX BOLT 5/8-11 X 9
59 P1014Z059 IDLER SHAFT V3.08.97
62B P1014Z062B ROLLER ADJUST BAR
64 P1014Z064 IDLER ROLLER V3.08.97
69 P1014Z069 MITER BODY
70 P1014Z070 TILT SCALE
71 P1014Z071 POWER CORD 16G 3W 73" 5-15P
77 P1014Z077 HEX WRENCH 4MM
80 P1014Z080 KEY 5 X 5 X 40
81A P1014Z081A ROCKER PLATE
82A P1014Z082A SHORT LEVER
83A P1014Z083A ROCKER ARM
84A P1014Z084A ECCENTRIC
85A P1014Z085A LONG LEVER
86A P1014Z086A KNOB 3/8-16
87A P1014Z087A SPACER
88A P1014Z088A HEX BOLT 3/8-16 X 3/4
89 P1014Z089 CAP SCREW 10-24 X 5/8
90 P1014Z090 MOTOR CORD 16G 3W 12"
91 P1014Z091 HEX BOLT 3/8-16 X 1-1/2
92 P1014Z092 FLAT WASHER 3/8
93 P1014Z093 WASHER PLATE 19 X 88
94A P1014Z094A KNOB 3/8-24
95 P1014Z095 LOCK WASHER 5/16
96 P1014Z096 SET SCREW 5/16-18 X 3/4
97 P1014Z097 FENDER WASHER 5/16 X 21 X 2
98 P1014Z098 HEX NUT 3/8-16
99 P1014Z099 GRAPHITE PAD 6"W X 17"L
100 P1014Z100 DUST PORT
101 P1014Z101 FENDER WASHER 3/8
102 P1014Z102 BELT DIRECTION ARROW
103 P1014Z103 TABLE TILT POINTER
105 P1014Z105 HEX NUT 3/8-16
106 P1014Z106 LOCK WASHER 5MM
107 P1014Z107 HEX BOLT 1/4-20 X 1/2
108 P1014Z108 FLAT WASHER 1/4
114A P1014Z114A IDLER ROLLER GUARD V2.03.08
114A-1 P1014Z114A-1 SLEEVE GUARD
115 P1014Z115 LOCK KNOB 1/4-20
116 P1014Z116 FLAT WASHER 1/4
117 P1014Z117 FLAT WASHER 5/16
118 P1014Z118 PHLP HD SCR 10-24 X 3/8
119 P1014Z119 DUST PORT (ABS) 2-1/2"
120 P1014Z120 MOTOR LABEL
126 P1014Z126 LOCK KNOB 10-32
127 P1014Z127 FLAT WASHER #10
137 P1014Z137 LOCK WASHER #10
138 P1014Z138 EXT TOOTH WASHER #10
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
-55-
