33. Install the 2" dust port onto the back of the
sanding belt frame with the pre-installed
20 x ⁄ " hex bolts and
1
2
shown in Figure 38.
Figure 38. 2" dust port installed.
34. Assemble the quick release lever, as shown
in Figure 39, using the handle, 6" quick
release lever stud, short lever arm, and (2)
⁄ "-16 hex nuts.
3
8
35. Thread the assembly from Step 34 into the
rocker arm, then tighten the hex nuts (see
Figure 39).
Hex Nuts
Rocker
Arm
Short
Lever
Arm
Figure 39. Quick release lever installed.
-26-
1 ⁄ "-
4
⁄ " flat washers, as
1
4
2" Dust
Port
6" Stud
Handle
36. Move the quick release lever toward the
motor, slide the sanding belt over the lever
and onto the idler roller and drive rollers, then
center the belt on the rollers (see Figure 40).
Idler
Roller
Figure 40. Belt installed onto idler and drive
rollers.
37. Push the lever toward the motor to tension
the sanding belt.
38. Assemble idler roller guard with (2) M5-.8
x 10 thumb knobs, #10 lock washers, and
#10 flat washers, then loosen thumb knobs
behind idler roller, and install idler roller
assembly (see Figure 41).
Thumb Knob
Figure 41. Idler roller guard installed.
Model G1014Z/G1014ZX (Mfd. Since 08/22)
Drive Roller
Idler Roller Guard
