Settings

1
Disassemble
1
Jumper pin settings
2
JP1
Alarm output mode
N.C. (default)
Light control mode settings
3
Assemble
4
Open the base cover, and to set the detector.
JP2
PIR sensitivity
Turn the jumper PIN
by 90 degrees to prevent
interference with the casing.
N.O.
30
&
2 120
Time(s) LUX
Security mode (default)
Close the base cover, and fasten the screw to fix the cover.
H
(recommended)
Mounting height: > 3.5 m
30
&
2 120
Time(s) LUX
Light control mode
4
M L
(default)
3.0 to 3.5 m < 3.0 m
(11'6") (9'10" to 11'6") (9'10")
