Port
NET (0-2)
NET MGT
SER MGT (COM1)
Description
From left to right:
• 1 GigE ports - Net 0
• 10 GigE ports - Net 1, Net
2
Enables you to connect the
Netra X7-2 to your network.
Provides a 10/100/1000
BASE-T Ethernet connection
to the Service Processor (SP)
through an RJ-45 connector.
The NET MGT port provides
support connections to the SP
using the Oracle Integrated
Lights Out Manager (ILOM)
CLI and Web interface. By
default, the NET MGT port is
configured to use DHCP to
automatically obtain an IP
address. Alternatively, you can
assign a static IP address to
the NET MGT port. To use the
NET MGT port, you must
configure its network settings.
Once configured, use the NET
MGT port IP address to log on
to the device using a browser
or secure shell.
Provides a TIA/EIA-232 serial
Oracle/Cisco standard
connection to the SP through
an RJ-45 connector.
This interface connects to
either Service Processor by
default, but can be redirected
to the host.
Default settings:
• 8N1: eight data bits, no
parity, one stop bit
• 9600 baud (change to
115200 baud)
• Disable hardware flow
control (CTS/RTS)
• Disable software flow
control (XON/XOFF)
Chapter 3
Cable the Oracle X7-2
You Need:
A Category 6 (or better)
Ethernet cable to connect to
the NET 0 port to your network
Network parameters such as
an IP address (can be
provided by DHCP services or
assigned a static address in
the OS)
Additional Category 6 (or
better) Ethernet cables and
Ethernet addresses as needed
for additional connections to
NET 0, 1 and 2.
Category 6 (or better)
Ethernet cable to connect the
NET MGT port to your network
IP address for this port
(required from DHCP or a
static address)
A terminal device (e.g.,
terminal, connection to a
terminal server, or computer
such as a laptop running
terminal emulation software)
A cable to connect the
terminal device to the SER
MGT (COM1) port
