Parameter
name
operation-type
port
slot
virtual-mac
admin-state
auto-negotiation
duplex-mode
speed
wancom-health-score
R = Required, O = Optional, I = Invalid

Acme Packet 1100 Physical Interfaces

The Acme Packet 1100 back panel comprises its primary network interface unit (NIU).
The back panel includes the majority of the Acme Packet 1100's external interfaces,
including console, alarm, network management and media interfaces. There is an
optional 1-port T1/E1 NIU available for sending signaling traffic to the WAN as a
backup voice channel. There is also a USB port on the front panel.
The graphic below shows the location and labeling of the Acme Packet 1100 media
and network management ports. This labeling is an important point of reference when
you set up the phy-interface configuration element.
Figure A-1
The Acme Packet 1100 NIU includes the following ports (from left to right).
• USB—For use only by Oracle personnel.
• SER MGT (Console)—Provides serial access for administrative and maintenance
purposes.
• NET MGT (wancom0)—The system uses these 10/100/1000 Base-T Ethernet
ports for device management functions and HA.
Network Media Interface
R
R
R
R
O
R
R
R
R
I
Acme Packet 1100 - Rear View
Appendix A
Acme Packet 1100 Physical Interfaces
Wancom1 and wancom2
Network Management
Interfaces
R
R
R
R
I
I
I
I
I
O
