Connect ILOM to the Netra X5 for Communications

Use the following procedure to make a connection to the Netra X5-2 for Communications
Oracle Integrated Lights Out Manager (ILOM) port. For a remote permanent connection to
the Service Processor over the ILOM connection, use the rear panel NET MGT port.
Note:
Keep Ethernet cables separated from power cables by at least 60mm where
possible and never run them in the same channel of the rack without segregation.
•
Locate the cable to connect to the Netra X5-2 for Communications.
1.
Plug the RJ-45 connector into the ILOM port.
2.
Figure 2-5
Lead the cable neatly away from the rear panel.
3.
Connect the other end of the cable to the LAN.
4.
• Refer to the Netra X5-2 for Communications hardware documentation for information on
how to configure the Web browser application to connect to the console, and how to
establish communications with the Netra X5-2 for Communications.

Software Installation - Netra and Server-based Platforms

Oracle Communications Session Delivery software requires software installation when
deployed on Netra and Server-based platforms.
Installation Procedure
Software installation to Netra and server-based platforms includes the following high-level
steps:
Ensure your device is set to boot from your boot media. This may be by way of USB or
1.
CD.
Insert your installation media in any USB slot or CD drive.
2.
Power up the device, observing the boot cycle.
3.
Category 6 (or better) Ethernet cable with RJ-45 jacks
Connecting to ILOM Port
Software Installation - Netra and Server-based Platforms
