DEMO MANUAL
DC2510A

ABSOLUTE MAXIMUM RATINGS

Supply Voltage on VSUPPLY ................................................................................................................................ 4.20V
Input Voltage on ADC Inputs .................................................................................................................................1.98V
Voltage on Any Digital I/O Pin ...............................................................................................–0.3V to VSUPPLY + 0.3V

SPECIFICATIONS

PIN TYPE PIN
Power VSUPPLY
ADCs
GPIO,
I/O
UART,
2
I C,
SPI
2
PARAMETER
Input Voltage Range
Low Input Voltage
High Input Voltage
Low Output Voltage
High Output Voltage
Pull-Up/Pull-Down Resistance
Figure 2. Board Layout Organization Diagram
TYPICAL/
MIN DEFAULT
2.1 3.3
0
–0.3
VSUPPLY VSUPPLY
–0.3
VSUPPLY VSUPPLY
–0.3
50
MAX UNITS
3.76 V
1.8 V
0.6 V
V
+0.3
0.4 V
V
+0.3
kΩ
