Chapter 6
Appendix A
A.1 Rear Panel Motor Control Connector
The 'Motor' connector provides connection to the stepper motor actuator. The pin
functions are detailed in Fig. A.1.
Pin
1
2
3
4
5
6
7
8
Notes.
* Pull low to enable.
40
Rear Panel Connector Pinout Details
5
10
15
Description
Ground
CCW Limit Switch
CW Limit Switch
Phase B -ve
Phase B +ve
Phase A -ve
Phase A +ve
For Future Use
Fig. A.1 MOTOR I/O Connector Pin Identification
1
6
11
Pin Description
9
10 +5V
11 Enc A +ve
12 Enc A -ve
13 Enc B +ve
14 Enc B -ve
15 For Future Use
HA0333T Rev BK Sept 2015
