THORLABS TST101 User Manual page 35

T-Cube Stepper Motor Controller
6.3.4 Stage/Axis Tab
Fig. 6.7 Stepper Driver T-Cube - Stage/Axis Settings
Note
This tab contains a number of parameters which are related to the physical
characteristics of the particular stage being driven. They need to be set
accordingly such that a particular stage is driven properly by the system.
For Thorlabs stages, the Kinesis software can be used to associate a specific
stage and axis type with the motor channel (see Section 3.5. for further details
on how to associate a stage and axis). Once this association has been made,
the Kinesis server will automatically apply suitable defaults for the
parameters on this tab during boot up of the software and these parameters
cannot be altered subsequently as it may adversely affect the performance of
the stage. Descriptions are provided for information only.
For custom stage types not available using the Kinesis software, the stage
details must be entered manually - see the software overview for more details.
