Hardware Installation and Reference Guide
Item
Port mode
switch-over button
System status
indicator (PWR)
DC power socket
Grounding pole
1.2.5

Technical Specifications

Table 1-2 Technical Specifications of an RG-ES106D-P Switch
Product Model
Ports
Power Supply
PoE
Power
Consumption
Operating
Temperature
Description
Support switchover in three modes:
Left：Flow Control On
Middle: Flow Control Off
Right: Port Isolation. When this mode is enabled, ports 1-4 are isolated from
each other, but can communicate with ports 5-6.
System status indicator. The statuses are as follows:
Solid green: The system is operational.
Off: The switch is not powered on.
Used to Connect the DC power adapter（51 VDC/1.25 A）
Used to fasten the ground cable.
RG-ES106D-P
6 10/100Base-TX auto-sensing Ethernet ports, ports 1-4 support PoE/PoE+.
AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
Frequency: 50/60Hz
Rated current: 1.5 A
Adapter output
Rated voltage range: 51 VDC
Rated current range: 1.25 A
Support PoE and PoE+.
Ports 1-4 are PoE/PoE+-capable with the maximum power output of 30W per port. Ports
5-6 do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 58W.
Less than 7W with no PoE load
Less than 67W with PoE full load
0° C to 45° C(32° F to 113° F)
