R-NIS3100 Switch GHardware Installation and Reference Guide
Note
The package contents above are intended to provide a general overview, and are subject to the terms of the
order contract. Check your goods carefully against the order contract. If you have any questions, please
contact the distributor.
1.3

RG-NIS3100-8GT4SFP-HP

1.3.1

Technical Specifications

Model
CPU
BootROM
Flash Memory
SDRAM
Optical Module
SFP Port
Power Supply
Ground-Leakage
Current
EEE
PoE
PoE Power Cable
Pairs
RG-NIS3100-8GT4SFP-HP
Built-in MAC chip, 500 MHz single-core processor
N/A
16 MB
DDR3 256 MB
See Appendix B. Direct Attach Copper (DAC) cables are not supported.
Note
The supported module types may update without prior notice. Please
contact Ruijie Networks for details.
The SFP port supports 1000BASE-X and 100BASE-FX.
DC input:
Rated voltage range: 12 V to 56 V
Rated current: 7 A
≤ 3.5 mA
Supported
All RJ45 ports are PoE capable and each port provides up to 30 W of PoE power.
Maximum overall PoE/PoE+ output power: 240 W
The PoE port is PoE/PoE+ capable.
The maximum number of PoE devices supported by the switch is determined by
the input voltage and PoE output power of the switch as well as the actual power of
the PoE devices.
Mode A (1-2 and 3-6 pairs)
2
