- Page 1 Ruijie Reyee RG-ES110F-P Switch Installation Guide Document Version: V1.2 Date: 2024-07-23 Copyright © 2024 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
-
Page 3: Preface
Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support The official website of Ruijie Reyee: https://reyee.ruijie.com Technical Support Website: https://reyee.ruijie.com/en-global/support Case Portal: https://www.ruijienetworks.com/support/caseportal Community: https://community.ruijienetworks.com... - Page 4 Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Overview ..........................1 1.1 Package Contents........................1 1.2 Appearance ..........................1 1.2.1 Front Panel ........................2 1.2.2 Rear Panel ........................3 1.3 Technical Specifications ......................4 1.4 Cooling ............................5 2 Preparing for Installation ........................6 2.1 Safety Precautions ........................ - Page 6 2.2.9 Installation Site Requirements ..................10 2.3 Tools ............................10 3 Installing the Switch ......................... 11 3.1 Before You Begin ........................11 3.2 Precautions ..........................11 3.3 Mounting the Switch ........................ 12 3.3.1 Mounting the Switch on a Wall ..................12 3.3.2 Mounting the Switch on a Workbench .................
-
Page 7: Product Overview
Installation Guide Product Overview Product Overview The RG-ES110F-P switch is a 100 Mbps Ethernet PoE switch featuring ten 10/100 Mbps ports with auto- negotiation and line-rate forwarding performance. As the eight downlink ports are PoE-capable and are backward compatible with the IEEE802.3at standard, the RG-ES110F-P switch can automatically detect and supply power to devices compliant with IEEE802.3at/af standards through Ethernet cables. -
Page 8: Front Panel
Installation Guide Product Overview Figure 1-1 Appearance of a RG-ES110F-P Switch 1.2.1 Front Panel Figure 1-2 Front Panel of a RG-ES110F-P Switch Table 1-2 Front Panel Components Component Description Off: The device is not powered on. System LED Solid on: The device is powered on. -
Page 9: Rear Panel
Installation Guide Product Overview Component Description The DIP switch is used to adjust the switch's working mode. Default mode: All ports can communicate with each other. Extend mode: The rate of ports 1 to 8 is reduced to 10 Mbps. Typically, the transmission distance is 200 m (656.17 ft), which is up to 250 m (820.21 ft) in the laboratory environment with Cat5e DIP switch... -
Page 10: Technical Specifications
Installation Guide Product Overview Table 1-3 Rear Panel Components Component Description Connect the AC power cord to the AC power connector to supply power to AC power connector the switch. Connect to the protective ground through the grounding wire to provide Grounding stud grounding protection. -
Page 11: Cooling
Installation Guide Product Overview Model RG-ES110F-P Port Surge Common Mode 4KV Protection Number of Fans Fanless Certification Ground Leakage ≤ 3.5 mA Current Dimensions 166 mm x 132.6 mm x 43 mm (6.54 in. x 5.22 in. x 1.69 in.) (W x D x H) Gross Weight 1.2 kg (2.65 lbs) -
Page 12: Preparing For Installation
Installation Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid bodily injury and device damage, please carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ... -
Page 13: Esd Safety
Installation Guide Preparing for Installation maximum leakage current of all the power supplies in the system. For example, if a system is equipped with 16 identical power supplies, and the leakage current of each power supply is equal to or less than 3.5 mA, then the leakage current of the system totals 56 mA. -
Page 14: Temperature And Humidity Requirements
Installation Guide Preparing for Installation 2.2.4 Temperature and Humidity Requirements For optimal device performance and extended service life, it is essential to maintain suitable temperature and humidity conditions in the equipment room. Prolonged exposure to excessively high or low temperature and humidity can potentially cause damage to the device. -
Page 15: Grounding Requirements
Installation Guide Preparing for Installation Average (mg/m Maximum (mg/m Nitrogen dioxide (NO Chlorine gas (CI Note "Average" indicates the typical level of exposure over a one-week period, while "Maximum" refers to the highest allowable exposure level within a week, with this level being sustainable for no more than 30 minutes per day. -
Page 16: Anti-Interference Requirements
Installation Guide Preparing for Installation 2.2.7 Anti-interference Requirements Take interference prevention measures for the power supply system. Keep the device away from the grounding equipment or lightning and grounding equipment of the power device as much as possible. ... -
Page 17: Installing The Switch
Installation Guide Installing the Switch Installing the Switch Caution Before installing the switch, carefully read Chapter 2 and make sure that all the requirements in Chapter 2 are met. Before You Begin The installation site provides sufficient space for heat dissipation. ... -
Page 18: Mounting The Switch
Installation Guide Installing the Switch Mounting the Switch 3.3.1 Mounting the Switch on a Wall Note The RG-ES110F-P switch can be mounted on a wall (You need to prepare two KA 3 x 25 mm screws and two expansion anchors by yourself). The installation steps are as follows: (1) Take out two expansion anchors and two screws from the package. -
Page 19: Mounting The Switch On A Workbench
Installation Guide Installing the Switch 3.3.2 Mounting the Switch on a Workbench If it is impossible to mount the switch on a wall, an alternative approach is to place it on a clean workbench. Do not relocate the workbench once the device has been mounted and is in operation to ensure stability and safety. Figure 3-2 Mounting the Switch on a Workbench Grounding the Switch... -
Page 20: Debugging
Installation Guide Debugging Verify that cables are routed indoors. If not, verify that the power supply and ports are protected from lightning strikes. Verify that a minimum clearance of 100 mm (3.94 in.) is maintained around the device for heat dissipation. Debugging Powering on the Switch 4.1.1... - Page 21 Installation Guide Debugging (2) Tap the Topology button, and select the existing managed device. To add an unmanaged downlink switch by scanning its QR-code, select Scan to Add. (3) After the device is detected, select its uplink port. And the device is added successfully.
-
Page 22: Adding Unmanaged Device Manually
Installation Guide Debugging 4.2.2 Adding Unmanaged Device Manually (1) Tap Topology to enter the topology page. (2) Tap the Topology button, and select the existing managed device. To add an unmanaged downlink switch manually, select Manually Add. (3) Select the device model and its uplink port, and the device is added successfully. -
Page 23: Appendix
Installation Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Ports A 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps Ethernet port that supports auto MDI/MDIX. Compliant with the IEEE 802.3ab standard, a 1000BASE-T port requires Category 5 100-ohm UTP or Category 5e UTP/STP (STP is recommended) cables with a maximum distance of 100 meters (328 ft.). The 1000BASE-T port uses four pairs of wires for data transmission, as shown in Figure 5-1. -
Page 24: Lightning Protection
Installation Guide Appendix Figure 5-2 100BASE-TX/10BASE-T Pin Assignments Figure 5-3 shows the wiring of straight-through and crossover cables for 100BASE-TX/10BASE-T ports. Figure 5-3 100BASE-TX/10BASE-T Connection Lightning Protection 5.2.1 Installing the AC Power Arrester The AC power connector must be connected to an external lightning protection power strip to prevent the switch from being struck by lightning when the AC power cord is introduced from the outdoor and directly connected to the power connector of the switch. -
Page 25: Installing The Ethernet Port Arrester
Installation Guide Appendix Figure 5-4 AC Power Arrester Caution The power arrester is not delivered with the switch, and needs to be purchased separately based on actual requirements. Precautions for installation: Ensure that the PE terminal of the power arrester is well-grounded. ... - Page 26 Installation Guide Appendix sided adhesive tape and paste the Ethernet port arrester to the switch housing. The paste position for the Ethernet port arrester should be as close to the grounding stud of the switch as possible. (2) Based on the distance between the switch grounding stud and the Ethernet port arrester, cut the grounding wire for the Ethernet port arrester and firmly tighten the grounding wire to the grounding stud of the switch.
- Page 27 Installation Guide Appendix Insufficient arresters. If there is more than one port on the switch connected to a device, an arrester needs to be installed on each connected port for lightning protection.
