- Page 1 RG-ES1 Series Switch RG-ES106D-P&RG-ES126S-LP&RG-ES110D-P&RG-ES118S-LP& RG-ES116G&RG-ES124GD Hardware Installation and Reference Guide Document Version: V1.4 Date: 2024-02-01 Copyright © 2024 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks website: https://www.ruijienetworks.com/ Technical support website: https://ruijienetworks.com/support...
- Page 4 Signs The signs used in this document are described as follows. Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Table Of Contents
Contents Product Overview ..........................1 RG-ES106D-P ........................1 RG-ES126S-LP ........................4 RG-ES110D-P ........................7 RG-ES118S-LP ........................11 RG-ES116G........................14 RG-ES124GD ........................17 Preparation Before Installation......................21 Safety Suggestions ......................21 2.1.1 Installation ........................21 2.1.2 Movement ........................21 2.1.3 Electricity ........................21 2.1.4 Static Discharge Damage Prevention ................. - Page 6 Appendix B Surge Protection ........................40 Appendix C Cabling Recommendations in Installation ................43 Appendix D Site Selection ........................47...
-
Page 7: Product Overview
Hardware Installation and Reference Guide Product Overview 1 Product Overview The RG-ES100 series switches include the following models. 10/100/1000Base-T 10/100Base-TX Auto-sensing 1000Base-X SFP Console Model Auto-sensing Ethernet Port Port Port Ethernet Port RG-ES106D-P 6 (ports 1–4 support PoE/PoE+) RG-ES126S-LP 24 (ports 1–24 support PoE/PoE+) 1 (combo) RG-ES110D-P 8 (ports 1–8 support PoE/PoE+) - Page 8 Hardware Installation and Reference Guide Product Overview Storage -40° C to +70° C (-40° F to +158° F) Temperature Operating Humidity 10% to 90% RH Storage Humidity 5% to 95% RH Switchover in three modes: 1. Flow Control On 2. Flow Control Off Port Mode 3.
- Page 9 Hardware Installation and Reference Guide Product Overview Note: 1. Electrical port status LED 2. PoE status LED 3. 10/100Base-TX PoE port 4. 10/100Base-TX auto-sensing Ethernet port 5. Nameplate on the bottom of the device Back Panel Figure 1-3 Back Panel of the RG-ES106D-P Note: 1.
-
Page 10: Rg-Es126S-Lp
Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning The switch is powered off. System status LED Solid green The switch is operational. The port is not connected. Upper left corner of the Solid green The port is connected at a rate of 10/100 Mbps. RJ45 port status LED port The port is receiving or sending traffic at a rate of... - Page 11 Hardware Installation and Reference Guide Product Overview Storage -40° C to +70° C (-40° F to +158° F) Temperature Operating Humidity 10% to 90% RH Storage Humidity 5% to 95% RH Sswitchover in three modes: 1. Flow Control On 2. Flow Control Off Port Mode 3.
- Page 12 Hardware Installation and Reference Guide Product Overview Note: 1. PoE overload LED 6. 10/100Base-TX auto-sensing Ethernet port 2. System status LED 7. 10/100/1000Base-T auto-sensing Ethernet port 3. Port status LED 8. 10/100/1000Base-T combo port 4. PoE status LED 9. Nameplate on the bottom of the device 5.
-
Page 13: Rg-Es110D-P
Hardware Installation and Reference Guide Product Overview The overall PoE output does not reach the maximum power. PoE overload LED PoE-max The overall PoE output reaches the maximum Solid green power. The port is not connected. The port is connected at a rate of 10/100/1000 Solid green Mbps. - Page 14 Hardware Installation and Reference Guide Product Overview Ports 1 to 8 support PoE/PoE+ with the maximum power output of 30 W per port. Ports 9–10 do not support PoE or PoE+. The overall maximum output power of PoE/PoE+ is 110 W. Power Less than 8 W with no PoE load Consumption...
- Page 15 Hardware Installation and Reference Guide Product Overview Front Panel Figure 1-8 Front Panel of the RG-ES110D-P Note: 1. System status LED 2. Port status LED 3. PoE status LED 4. 10/100Base-TX PoE port 5. 10/100/1000Base-T auto-sensing Ethernet port 6. Nameplate on the bottom of the device Back Panel Figure 1-9 Back Panel of the RG-ES110D-P...
- Page 16 Hardware Installation and Reference Guide Product Overview Note: 1. Grounding pole 2. Port mode switchover button 3. DC power socket Heat Dissipation The RG-ES110D-P adopts natural heat dissipation, thereby ensuring normal operation. You must maintain a minimum clearance of 100 mm (3.94 in.) around the RG-ES110D-P. It is recommended that you clean the RG-ES110D-P once every three months to avoid dust from blocking vents.
-
Page 17: Rg-Es118S-Lp
Hardware Installation and Reference Guide Product Overview 1.4 RG-ES118S-LP Technical Specifications Model RG-ES118S-LP Sixteen 10/100Base-TX auto-sensing Ethernet ports (auto MDI/MDIX), and PoE/PoE+ support Ports Two 1000Base-X SFP combo ports AC input Rated voltage range: 100 V AC to 240 V AC Power Supply Maximum voltage range: 90 V AC to 264 V AC Frequency: 50/60 Hz... - Page 18 Hardware Installation and Reference Guide Product Overview (With Package) Device operation in a residential environment may cause radio interference. Product Appearance The RG-ES118S-LP provides sixteen 10/100Base-TX auto-sensing Ethernet ports, two 1000Base-X SFP combo ports, a port mode switchover button and LED indicators on the front panel, and a power socket and a grounding pole on the back panel.
- Page 19 Hardware Installation and Reference Guide Product Overview Note: 1. Grounding pole 2. AC power socket Heat Dissipation The RG-ES118S-LP adopts fans for heat dissipation, thereby ensuring normal operation. You must reserve 10 cm distance space at both sides and the back plane of the cabinet to allow airflow. It is recommended that you clean the RG-ES118S- LP once every three months to avoid dust from blocking vents.
-
Page 20: Rg-Es116G
Hardware Installation and Reference Guide Product Overview The port is receiving or sending traffic at a rate of Blinking orange 100 Mbps. Solid green The port is connected at a rate of 1000 Mbps. The port is receiving or sending traffic at a rate of Blinking green 1000 Mbps. - Page 21 Hardware Installation and Reference Guide Product Overview 4. Extend Data Transmission-10Mbps: When this mode is enabled, ports 1–8 have a reduced speed of 10 Mbps, with a transmission distance of up to 250 m. If compatibility is considered, some ports may not deliver such a transmission distance. Not supported Temperature Not supported...
- Page 22 Hardware Installation and Reference Guide Product Overview Note: 1. System status LED 2. Port status LED 3. Port mode switchover button 4. 10/100/1000Base-T auto-sensing Ethernet port 5. Nameplate on the bottom of the device Back Panel Figure 1-12 Back Panel of the RG-ES116G Note: 1.
-
Page 23: Rg-Es124Gd
Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning The switch is powered off. System status LED Power Solid green The switch is operational. The port is not connected. Solid orange The port is connected at a rate of 10/100 Mbps. The port is receiving or sending traffic at a rate of Blinking orange RJ45 port status LED... - Page 24 Hardware Installation and Reference Guide Product Overview 2. Flow Control Off 3. Port Isolation When port isolation is enabled, ports 1-22 are isolated from each other, but can communicate with ports 23 and 24. 4. Extend Data Transmission-10Mbps: When this mode is enabled, ports 1–8 have a reduced speed of 10 Mbps, with a transmission distance of up to 250 m.
- Page 25 Hardware Installation and Reference Guide Product Overview Note: 1. System status LED 2. Port status LED 3. Port mode switchover button 4. 10/100/1000Base-T auto-sensing Ethernet port 5. Nameplate on the bottom of the device Back Panel Figure 1-12 Back Panel of the RG-ES124GD Note: 1.
- Page 26 Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning The switch is powered off. System status LED Power Solid green The switch is operational. The port is not connected. Solid orange The port is connected at a rate of 10/100 Mbps. The port is receiving or sending traffic at a rate of Blinking orange RJ45 port status LED...
-
Page 27: Preparation Before Installation
2 Preparation Before Installation 2.1 Safety Suggestions To avoid personal injury and device damage, carefully read the safety suggestions before you install the RG-ES100 series switch. The following safety suggestions do not cover all possible dangers. 2.1.1 Installation Keep the chassis clean and free from any dust. ... - Page 28 each power supply is equal to or less than 1.5 mA, and the total leakage current of the system is 30 mA. A leakage protector with 30 mA rated action current supports less than ten power supplies (that is, action current of the leakage protector/2/maximum leakage current of each power supply = 30/2/1.5 = 10).
- Page 29 Installation Tools ......................... 26 Product Installation ..........................27 Installation Flowchart ......................27 Precautions Before Installation................... 27 Installing the RG-ES100 ..................... 28 3.3.1 Mounting the Switch in a Standard 19-inch Rack ............28 3.3.2 Mounting the Switch Against a Wall ................30 3.3.3 Mounting the Switch on a Table ..................
-
Page 30: Static Discharge Damage Prevention
Hardware Installation and Reference Guide Preparation Before Installation Product Overview. 2.1.4 Static Discharge Damage Prevention To prevent damage from static electricity, pay attention to the following points: Proper grounding of grounding screws on the back panel of the device ... -
Page 31: Cleanness
Hardware Installation and Reference Guide Preparation Before Installation The ambient temperature and humidity of the RG-ES100 series switch must meet the requirements listed in Table 2-1. Table 2-1 Temperature and Humidity Requirements of the RG-ES100 Series Switch Temperature Relative Humidity 0°... -
Page 32: Grounding
Hardware Installation and Reference Guide Preparation Before Installation The AC power supplying system is the TN system. The single-phase three-wire socket with protecting grounding must be used as the socket for the power supply to enable the device’s upper filter circuit to effective filter the power interface. -
Page 33: Lightning Resistance
Hardware Installation and Reference Guide Preparation Before Installation should be less than 1 Ω. The RG-ES100 series switch back plane is reserved with one grounding pole, as shown in Figure 2-1. Figure 2-1 Grounding of the RG-ES100 2.2.6 Lightning Resistance When the AC power cable is imported outdoors and directly connected to the power port of the RG-ES100 series switch, use the lightning line bank to prevent the switch from being hit by lightning shocks. -
Page 34: Installation Tools
Hardware Installation and Reference Guide Preparation Before Installation Lay interface cables inside the equipment room. Outdoor cabling is prohibited, avoiding damages to device signal interfaces caused by over-voltage or over-current of lightning. 2.3 Installation Tools Table 2-4 Installation Tools Phillips screwdriver, cables, bolts, diagonal pliers, and straps Common Tools Special Tools... -
Page 35: Product Installation
Hardware Installation and Reference Guide Product Installation 3 Product Installation 3.1 Installation Flowchart 3.2 Precautions Before Installation Before installation, confirm the following points: Check whether ventilation requirements are met for the switch. -
Page 36: Installing The Rg-Es100
Hardware Installation and Reference Guide Product Installation Check whether the requirements of temperature and humidity are met for the switch. Check whether power cables are already laid out and whether the requirements of electrical current are met. Check whether related network adaption lines are already laid out. - Page 37 Hardware Installation and Reference Guide Product Installation Step 2: Use the supplied screws and cage nuts to securely attach the mounting brackets to the rack, as shown in Figure 3-3. Figure 3-3 Attaching the Brackets to the Rack （1）...
-
Page 38: Mounting The Switch Against A Wall
Hardware Installation and Reference Guide Product Installation （2） 3.3.2 Mounting the Switch Against a Wall The RG-ES106D-P and RG-ES110D-P can be mounted against the wall. Mounting screws and wall anchors are customer supplied. You need to determine the size and depth of the two mounting holes on the wall based on the sizes of wall anchors and screws. -
Page 39: Mounting The Switch On A Table
Hardware Installation and Reference Guide Product Installation It is suitable for mounting on the concrete or non-combustible surface only. 3.3.3 Mounting the Switch on a Table The RG-ES110D-P is used as an example. Place the switch on a table, as shown in Figure 3-2. Figure 3-5 Placing the Switch on a Table The device must be installed and operated in the place that can restrict its movement. -
Page 40: Adding An Unmanaged Device To The Topology
Hardware Installation and Reference Guide Product Installation 3.5 Adding an Unmanaged Device to the Topology Note: Devices including Reyee EG or ES2/NBS switches can be managed in the network. Scenarios: To add an unmanaged switch, select its uplink device, and scan the QR Code on the switch or manually add it to the topology. -
Page 41: Adding An Unmanaged Device Manually
Hardware Installation and Reference Guide Product Installation 3.5.2 Adding an Unmanaged Device Manually Tap Topology to access the topology page. Tap the Topology button, and select the existing managed device. To add an unmanaged downstream switch manually, select Manually Add. Select the device model and its uplink port. - Page 42 Hardware Installation and Reference Guide Product Installation...
-
Page 43: System Commissioning
Hardware Installation and Reference Guide System Commissioning 4 System Commissioning 4.1 Startup Check 4.1.1 Checking Before the Device Is Powered On The switch is well grounded. The power cable is correctly connected. The power supply voltage complies with the requirement of the switch. 4.1.2 Checking After Program Startup (Recommended) After power-on, you are advised to perform the following checks to ensure the normal operation of follow-up configurations. -
Page 44: Maintenance And Troubleshooting
Hardware Installation and Reference Guide Maintenance and Troubleshooting 5 Maintenance and Troubleshooting 5.1 Troubleshooting Procedure 5.2 Troubleshooting Common Faults Symptom Possible Causes Solution The status indicator is Check whether the power socket in the equipment The power module does not work. not on after the switch room is normal and whether the power cable is The power cable is in loose contact. - Page 45 Hardware Installation and Reference Guide Maintenance and Troubleshooting Symptom Possible Causes Solution The length of the optical fiber exceeds Replace the optical fiber with one of the appropriate that rated of the optical module. length.
-
Page 46: Appendix A Connectors And Connection Media
Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T supports adaptation of three rates and automatic MDI/MDIX crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m. - Page 47 Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Optical Fiber Connection For the optical fiber ports, select single-mode or multimode optical fibers for connections according to the optical module connected. Figure A-4 shows the connection schematic diagram. Figure A-4 Optical Fiber Connections...
- Page 48 Hardware Installation and Reference Guide Appendix B Surge Protection Appendix B Surge Protection Installing the AC Power Arrester (Surge Protection Cable Row) The external surge protection cable row must be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch.
- Page 49 Hardware Installation and Reference Guide Appendix B Surge Protection During the switch usage, the Ethernet port arrester must be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch. Tools: cross or straight screwdriver, multimeter, and diagonal pliers Installation steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the Ethernet port arrester.
- Page 50 Hardware Installation and Reference Guide Appendix B Surge Protection Poor arrester grounding: The grounding line must be as short as possible to ensure that it is in good contact with the switch grounding terminal. Use the multimeter to confirm the contact after grounding. ...
- Page 51 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Appendix C Cabling Recommendations in Installation When RG-ES100 series switches are installed in standard 19-inch cabinets, cables are tied in the binding rack on the cabinet by the cabling rack, and top or bottom cabling is adopted according to the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet in an orderly manner but not outside the cabinet.
- Page 52 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Cables of different types (such as power cords, signal cables, and ground cables) should be separated in cabling and bundling. When they are close, crossover cabling can be adopted. In the case of parallel cabling, maintain a space of at least 30 mm for power cords and signal cables.
- Page 53 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position will not affect device running or cause device or cable damage during commissioning.
- Page 54 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation The hard power cable should be fastened by the terminal connection area to prevent stress. Do not use self-tapping screws to fasten terminals. Power cables of the same type in the same cabling direction should be bundled up into cable bunches, with clean and straight cables in cable bunches.
- Page 55 Hardware Installation and Reference Guide Appendix D Site Selection Appendix D Site Selection The equipment room should be at least 5 km away from the heavy pollution source such as the smelter, coal mine, and thermal power plant, 3.7 km away from the medium pollution source such as the chemical industry, rubber industry, and electroplating industry, and 2 km away from the light pollution source such as the food manufacturer and leather plant.
