Hardware Installation and Reference Guide
Figure 1-6 Back Panel of RG-ES110D-P
Item
Grounding pole
Port mode
switch-over button
DC power socket
1.3.5 Technical Specifications
Table 1-4 Technical Specifications of an RG-ES110D-P Switch
Model
Ports
Power Supply
Description
Used to fasten the ground cable.
Support switchover in three modes:
Left: Flow Control On
Middle: Flow Control Off
Right: Port Isolation. When this mode is enabled, ports 1-8 are isolated from
each other, but can communicate with ports 9 and 10.
Used to Connect the DC power adapter（53.5 VDC/2.24 A）
RG-ES110D-P
8 10/100Base-TX auto-sensing Ethernet ports (Auto MDI/MDIX), and support PoE/PoE+
2 10/100/1000Base-T auto-sensing Ethernet ports (Auto MDI/MDIX)
AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
Frequency: 50/60Hz
Rated current: 1.6 A
Adapter output
Rated voltage range: 53.5 VDC
Rated current range: 2.24 A
8
Overview
