Summary of Contents for Ruijie Reyee RG-ES0 Series

Page 2 Unless agreed upon otherwise in the contract, Ruijie Networks does not provide any explicit or implicit statements or warranties regarding the content of this document.
Page 3: Preface
Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  The official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee  Technical Support Website: https://www.ruijienetworks.com/support  Case Portal: https://www.ruijienetworks.com/support/caseportal  Community: https://community.ruijienetworks.com...
Page 4 Notes This manual presents installation instructions, troubleshooting techniques, technical specifications, cable and connector requirements, and usage guidelines. It is intended for users who want to gain insight into the above content and have some experience in installing and maintaining network hardware. It is assumed that users are already familiar with relevant terms and concepts.
Page 5: Table Of Contents
Contents Preface ..............................I 1 Hardware Description ........................1 1.1 RG-ES05F ..........................1 1.1.1 Appearance ........................1 1.1.2 Technical Specifications ....................2 1.1.3 Cooling ........................... 3 1.1.4 LEDs ..........................3 1.2 RG-ES05G-L ..........................3 1.2.1 Appearance ........................3 1.2.2 Technical Specifications ....................4 1.2.3 Cooling ...........................
Page 6 1.5 RG-ES106F-P .......................... 12 1.5.1 Package Contents ......................12 1.5.2 Appearance ........................13 1.5.3 Technical Specifications ....................15 1.5.4 Cooling ......................... 16 1.6 RG-ES110FG-P ........................17 1.6.1 Package Contents ......................17 1.6.2 Appearance ........................17 1.6.3 Technical Specifications ....................19 1.6.4 Cooling .........................
Page 7 1.9.4 Cooling ......................... 33 1.10 RG-ES118FGS-LP ........................ 34 1.10.1 Package Contents ...................... 34 1.10.2 Product Appearance ....................34 1.10.3 Technical Specifications ..................... 36 1.10.4 Cooling ........................38 1.11 RG-ES118GS-P-L ......................... 38 1.11.1 Package Contents ...................... 38 1.11.2 Appearance ........................ 38 1.11.3 Technical Specifications .....................
Page 8 1.14.3 Technical Specifications ..................... 52 1.14.4 Cooling ........................54 2 Getting Started ..........................55 2.1 Preparing for Installation ......................55 2.1.1 Safety Precautions ....................... 55 2.1.2 Installation Environment Requirements ............... 56 2.1.3 Rack Installation Requirements ................... 59 2.1.4 Tools ..........................60 2.2 Installing the Switch .........................
Page 9: Hardware Description
Hardware Installation and Reference Guide Hardware Description Hardware Description RG-ES05F 1.1.1 Appearance On the front panel, the RG-ES05F switch provides five 10/100Base-T Ethernet ports and one DC power connector. Figure 1-1 Appearance of RG-ES05F Front Panel Figure 1-2 Front Panel of RG-ES05F 1.
Page 10: Technical Specifications
Hardware Installation and Reference Guide Hardware Description 1.1.2 Technical Specifications Table 1-1 Technical Specifications Model RG-ES05F Ports 5 x 10/100Base-T Ethernet ports with auto-negotiation AC input: Rated voltage range: 100 VAC to 240 VAC Maximum voltage range: 90 VAC to 264 VAC Frequency: 50/60 Hz Power Supply Rated current: 0.3 A...
Page 11: Cooling
Hardware Installation and Reference Guide Hardware Description IEC61000-4-5 Security Standards NE62386-1 Earth Leakage ≤ 1.5 mA Current Dimensions 85 mm x 52 mm x 23.5 mm (3.35 in. x 2.05 in. x 0.93 in.) (W x D x H) Weight 50 g (0.11 lbs.) (excluding packaging) Caution The RG-ES05F switch is a class A product.
Page 12: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Figure 1-3 Appearance of RG-ES05G-L Front Panel Figure 1-4 Front Panel of RG-ES05G-L Note: 1. 10/100/1000Base-T Ethernet port 2. Port status LED 3. System status LED 4. DC power connector 1.2.2 Technical Specifications Table 1-2 Technical Specifications Model...
Page 13 Hardware Installation and Reference Guide Hardware Description Adapter output: Rated voltage: 5 VDC Rated current: 1 A Not supported Not supported Power Consumption 2.1W Operating Temperature 0° C to 40° C (32° F to 104° F) –40° C to 70° C (–40° F to 158° F) Storage Temperature Operating Humidity 10% to 90% RH (non-condensing)
Page 14: Cooling
Hardware Installation and Reference Guide Hardware Description 1.2.3 Cooling The RG-ES05G-L switch adopts a natural cooling design to ensure normal functioning of the device. A minimum clearance of 100 mm (3.94 in.) must be maintained around the device for cooling. It is recommended to clean the device once every 3 months to avoid dust from blocking vents.
Page 15: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Figure 1-6 Front Panel of RG-ES08F Note: 1. 10/100Base-TX Ethernet port 2. Port status LED 3. System status LED 4. DC power connector 1.3.2 Technical Specifications Table 1-3 Technical Specifications Model RG-ES08F Ports 8 x 10/100Base-T Ethernet ports with auto-negotiation AC input: Rated voltage range: 100 VAC to 240 VAC...
Page 16: Cooling
Hardware Installation and Reference Guide Hardware Description –40° C to 70° C (–40° F to 158° F) Storage Temperature Operating Humidity 10% to 90% RH (non-condensing) Storage Humidity 5% to 90% RH (non-condensing) Not supported Over-temperature Not supported Alarm Optical Transceiver Not supported Module IEC55032...
Page 17: Leds
Hardware Installation and Reference Guide Hardware Description 1.3.4 LEDs Label State Description The switch is powered off. System status LED Solid on The switch is operating. The port is not connected. Port status Solid on The port is connected at 10/100 Mbps. The port is receiving or sending traffic at Blinking 10/100 Mbps.
Page 18: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Figure 1-8 Front Panel of RG-ES08G-L Note: 1. 10/100/1000Base-T Ethernet port 2. Port status LED 3. System status LED 4. DC power connector 1.4.2 Technical Specifications Table 1-4 Technical Specifications Model RG-ES08G-L Ports 8 x 10/100/1000Base-T Ethernet ports with auto-negotiation AC input: Rated voltage range: 100 VAC to 240 VAC...
Page 19 Hardware Installation and Reference Guide Hardware Description Operating 0° C to 40° C (32° F to 104° F) Temperature Storage –40° C to 70° C (–40° F to 158° F) Temperature Operating 10% to 95% RH (non-condensing) Humidity Storage Humidity 5% to 90% RH (non-condensing) Not supported Over-temperature...
Page 20: Cooling
Hardware Installation and Reference Guide Hardware Description 1.4.3 Cooling The RG-ES08G-L switch adopts a natural cooling design to ensure normal functioning of the device. A minimum clearance of 100 mm (3.94 in.) must be maintained around the device for cooling. It is recommended to clean the device once every 3 months to avoid dust from blocking vents.
Page 21: Appearance
Hardware Installation and Reference Guide Hardware Description 1.5.2 Appearance The RG-ES106F-P switch provides six 10/100Base-T ports with auto-negotiation, one DIP switch, one system LED and other LEDs on the front panel, and one AC power connector and one grounding stud on the rear panel. Figure 1-9 Appearance of a RG-ES106F-P Switch 1.
Page 22 Hardware Installation and Reference Guide Hardware Description The DIP switch is used to adjust the switch's working mode. Default mode: All ports can communicate with each other. Extend mode: The rate of ports 1 to 4 is reduced to 10 Mbps. Typically, the transmission distance is 200 m (656.17 ft), which is up DIP switch to 250 m (820.21 ft) in the laboratory environment with Cat5e cables...
Page 23: Technical Specifications
Hardware Installation and Reference Guide Hardware Description 1.5.3 Technical Specifications Table 1-8 Technical Specifications of a RG-ES106F-P Switch Model RG-ES106F-P Six 10/100 Mbps Ethernet ports with auto-negotiation Ports Ports 1-4 are PoE-capable. AC input: Rated voltage range: 100-240 V AC Power Supply Maximum voltage range: 90-264 V AC Maximum input current: 2 A...
Page 24: Cooling
Hardware Installation and Reference Guide Hardware Description Ground Leakage ≤ 3.5 mA Current Dimensions 166 mm x 132.6 mm x 43 mm (6.54 in. x 5.22 in. x 1.69 in.) (W x D x H) Weight 0.98 kg (2.16 lbs., with packaging materials) Warning Operation of this equipment in a residential environment could cause radio interference.
Page 25: Rg-Es110Fg-P
Hardware Installation and Reference Guide Hardware Description RG-ES110FG-P 1.6.1 Package Contents Table 1-9 Package Contents Item Quantity RG-ES110FG-P Switch Power Cord (1 m/3.28 ft.) Warranty Card User Manual Note The package contents are subject to the purchase contract, and actual delivery may vary. Please check the items carefully against the package contents or purchase contract.
Page 26 Hardware Installation and Reference Guide Hardware Description 1. Front Panel Figure 1-13 Front Panel of a RG-ES110FG-P Switch Table 1-10 Front Panel Components Component Description Off: The device is not powered on. System LED Solid on: The device is powered on. The DIP switch is used to adjust the switch's working mode.
Page 27: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Solid green: A 10/100/1000 Mbps link is established on the port. 10/100/1000Base-T auto- Blinking green: The port is sending and receiving traffic at 10/100 sensing Ethernet Mbps. port(G1,G2) Off: No link is established on the port. 2.
Page 28 Hardware Installation and Reference Guide Hardware Description Maximum voltage range: 90-264 V AC Maximum input current: 3 A Frequency: 50/60 Hz Not supported Compliant with IEEE 802.af/at Ports 1-8 are PoE/PoE+ capable. Maximum PoE+ output power per port: 30 W Maximum PoE/PoE+ output power per device: 110 W Power Cable...
Page 29: Cooling
Hardware Installation and Reference Guide Hardware Description 1.6.4 Cooling RG-ES110FG-P switch adopts the passive cooling design. A minimum clearance of 100 mm (3.94 in.) must be maintained around the device to ensure heat dissipation. Dust the device every three months to prevent vents from getting blocked.
Page 30 Hardware Installation and Reference Guide Hardware Description 1. Front Panel Figure 1-16 Front Panel of a RG-ES110F-P Switch Table 1-14 Front Panel Components Component Description Off: The device is not powered on. System LED Solid on: The device is powered on. The DIP switch is used to adjust the switch's working mode.
Page 31: Technical Specifications
Hardware Installation and Reference Guide Hardware Description 1. Rear Panel Figure 1-17 Rear Panel of a RG-ES110F-P Switch Table 1-15 Rear Panel Components Component Description Connect the AC power cord to the AC power connector to supply power to AC power connector the switch.
Page 32: Cooling
Hardware Installation and Reference Guide Hardware Description Power Cable Mode A (1-2, 3-6 pairs) Pairs 110 W (full PoE load) Maximum Power Consumption 10 W (no PoE load) Default mode: All ports can communicate with each other. Extend mode: The rate of ports 1 to 8 is reduced to 10 Mbps. Typically, the transmission distance is 200 m (656.17 ft), which is up to 250 m (820.21 ft) in the laboratory environment with Cat5e cables or higher.
Page 33: Rg-Es110Gs-P-L
Hardware Installation and Reference Guide Hardware Description RG-ES110GS-P-L 1.8.1 Package Contents Table 1-17 Package Contents Item Quantity RG-ES110GS-P-L Switch Power Cord (1 m/3.28 ft.) Warranty Card User Manual Note The package contents are subject to the purchase contract, and actual delivery may vary. Please check the items carefully against the package contents or purchase contract.
Page 34 Hardware Installation and Reference Guide Hardware Description 2. Front Panel Figure 1-19 Front Panel of a RG-ES110GS-P-L Switch Figure 1-20 Front Panel Components Component Description Off: The device is not powered on. System LED Solid on: The device is powered on. The DIP switch is used to adjust the switch's working mode.
Page 35: Technical Specifications
Hardware Installation and Reference Guide Hardware Description 100/1000M SFP Ethernet The 1000M self-adaptive Ethernet SFP port. Port Solid green: The port is sending and receiving traffic at 100/1000 Mbps. 100/1000Base-T SFP port Blinking green: The port is sending and receiving traffic at Link/Act LED (10F) 100/1000 Mbps.
Page 36 Hardware Installation and Reference Guide Hardware Description AC input: Rated voltage range: 110-240 V AC Power Supply Maximum voltage range: 100-264 V AC Maximum input current: 3 A Frequency: 50/60 Hz Not supported Compliant with IEEE 802.af/at Ports 1-8 are PoE/PoE+ capable. Maximum PoE+ output power per port: 30 W Maximum PoE/PoE+ output power per device: 120 W Power...
Page 37: Cooling
Hardware Installation and Reference Guide Hardware Description Warning Operation of this equipment in a residential environment could cause radio interference. 1.8.4 Cooling RG-ES110GS-P-L switch adopts the passive cooling design. A minimum clearance of 100 mm (3.94 in.) must be maintained around the device to ensure heat dissipation. Dust the device every three months to prevent vents from getting blocked.
Page 38: Rg-Es116G-L
Hardware Installation and Reference Guide Hardware Description RG-ES116G-L 1.9.1 Package Contents Table 1-19 Package Contents Name Quantity Remarks RG-ES116G-L Switch Rubber Feet Mounting Brackets Quick Installation Guide M4 x 8 mm Phillips Countersunk Screws Warranty Card Power Cord Note The package contents are subject to the purchase contract, and actual delivery may vary. Please check the items carefully against the package contents or purchase contract.
Page 39 Hardware Installation and Reference Guide Hardware Description 1. Front Panel Figure 1-23 Front Panel Table 1-20 Ports and Buttons on the Front Panel Interface Description information Off: the switch is not powered on. System status Fast blinking green (10 hz): the switch is upgrading or starting up and LED ( SYS ) cannot be used.
Page 40: Technical Specifications
Hardware Installation and Reference Guide Hardware Description 2. Rear Panel Figure 1-24 Rear Panel Table 1-21 Ports and Buttons on the Rear Panel Button and Description ports Power input Connects to an external AC power supply. connector Grounding Secures the grounding lug to connect the chassis to earth ground. screw 1.9.3 Technical Specifications...
Page 41: Cooling
Hardware Installation and Reference Guide Hardware Description Storage -40° C to 70° C (-40° F to 158° F) Temperature Operating Humidity 10% to 90% RH (non-condensing) Storage Humidity 5%~95% RH, no condensation Fan Modules Not supported Safety Standard Dimensions (W X D X H) 280mmx125mmx43.6mm (Unit: Mm)
Page 42: Rg-Es118Fgs-Lp
Hardware Installation and Reference Guide Hardware Description 1.10 RG-ES118FGS-LP 1.10.1 Package Contents Table 1-23 Package Contents Item Quantity RG-ES118FGS-LP Switch Mounting Brackets Power Cord M4 x 8 mm Screw User Manual Warranty Card Note The package contents are subject to the purchase contract. The actual delivery prevails. Please check the items carefully against the package contents or purchase contract.
Page 43 Hardware Installation and Reference Guide Hardware Description 1. Front Panel Figure 1-26 Front Panel of a RG-ES118FGS-LP Switch Table 1-24 Front Panel Specifications Item Description System Status LED Off: The switch is not powered on. Solid on: The switch is powered on. PoE Status LED Solid green: PoE is enabled.
Page 44: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Item Description 10/100 Base-TX Self-adaptive 16 10/100 Mbps self-adaptive Ethernet RJ45 ports Ethernet Ports (Auto MDI/MDIX) support PoE power supply. 10/100/1000 Base-X Combo Two 10/100/1000 Base-X combo port. The GE Port port and the copper port cannot be used at the same time.
Page 45 Hardware Installation and Reference Guide Hardware Description IEEE 802.3af-compliant and 802.3at-compliant Ports 1-16 support PoE power supply. Maximum PoE output power per port: 30 W Maximum PoE output power per device: 120 W PoE Power Cable Mode A (1-2, 3-6 pairs) Pairs 120 W (full PoE load) Maximum Power...
Page 46: Cooling
Hardware Installation and Reference Guide Hardware Description  You are advised to keep the device out of the reach of children. 1.10.4 Cooling The RG-ES118FGS-LP switch adopts fan cooling design. To ensure the normal operation of the device, maintain a minimum clearance of 10 cm (3.94 in.) around the device. Dust the device every three months to avoid blocking the ventilation openings.
Page 47 Hardware Installation and Reference Guide Hardware Description 1. Front Panel Figure 1-28 Front Panel Table 1-28 Front Panel Components Component Description Off: The switch is not powered on. Slow blinking green (flash every two seconds): The switch is operating properly, but has insufficient power for PoE. System LED Fast blinking green (10 flashes per second): The switch is upgrading or restarting.
Page 48: Technical Specifications
Hardware Installation and Reference Guide Hardware Description PoE status: Off: PoE is disabled. Solid green: PoE is enabled. 1000 Mbps Blinking green: PoE overload has occurred. Port status: Ethernet port Off: No link is established on the port. status LED Solid green: The port is operating at 10/100/1000 Mbps, but is not receiving or sending data.
Page 49 Hardware Installation and Reference Guide Hardware Description Model RG-ES118GS-P-L 16 x 10/100/1000Base-T ports with auto-negotiation Ports 2 x 1000 Mbps SFP ports Three work modes: Toggle to the far left position (Extend mode): The rate of ports 1 to 16 is reduced to 10 Mbps. Typically, the transmission distance is 200 m (656.17 ft), which is up to 250 m (820.21 ft) in the laboratory environment with Cat5e cables or higher.
Page 50: Cooling
Hardware Installation and Reference Guide Hardware Description Ports: common mode: ± 6 kV Weight 3.5 kg (7.72 lbs., with packaging) Danger Double pole/neutral fusing! Electrical Hazard. The fuse, located on the neutral line of the power supply unit, should be disconnected to cut off the power supply to the conductors in each phase.
Page 51: Product Appearance
Hardware Installation and Reference Guide Hardware Description 1.12.2 Product Appearance The RG-ES124G-L ethernet switch provides 24 1000M/100M/10M Base-T adaptive Ethernet ports, one toggle switch, and a series of LED indicators on the front panel. The rear panel provides an AC power input port and a ground pin.
Page 52: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Nameplate At the bottom of the device 2. Rear Panel Figure 1-31 Rear Panel Table 1-33 Ports and Buttons on the Rear Panel Button and Description ports Power input Connects to an external AC power supply. connector Grounding Secures the grounding lug to connect the chassis to earth ground.
Page 53: Cooling
Hardware Installation and Reference Guide Hardware Description Max. Power <14W Consumption Operating 0º C~45º C Temperature Storage Temperature -40º C~70º C Operating Humidity 10% to 90% RH (non-condensing) Storage Humidity 5%~95% RH, no condensation Fan Modules Not supported Safety Standard Dimensions (W X D X H) 280mmx125mmx43.6mm...
Page 54: Product Appearance
Hardware Installation and Reference Guide Hardware Description Power Cord M4 x 8 mm Screw User Manual Warranty Card Note The package contents are subject to the purchase contract. The actual delivery prevails. Please check the items carefully against the package contents or purchase contract. If you have any questions or there are any errors, please contact your distributor.
Page 55 Hardware Installation and Reference Guide Hardware Description Table 1-36 Front Panel Specifications Item Description System Status LED Off: The switch is not powered on. Solid on: The switch is powered on. PoE Status LED Solid green: PoE is enabled. Flashing green: PoE overload occurs. Off: PoE is disabled.
Page 56: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Item Description 10/100/1000 Base-X Combo One 10/100/1000Base-T combo port. The GE port Port and the copper port cannot be used at the same time. Nameplate On the bottom of the device 2. Rear Panel Figure 1-34 Rear Panel of a RG-ES126FGS-LP Switch Table 1-37...
Page 57 Hardware Installation and Reference Guide Hardware Description Ports 1-24 support PoE power supply. Maximum PoE output power per port: 30 W Maximum PoE output power per device: 180 W PoE Power Cable Mode A (1-2, 3-6 pairs) Pairs 180 W (full PoE load) Maximum Power Consumption 20 W (no PoE load)
Page 58: Cooling
Hardware Installation and Reference Guide Hardware Description 1.13.4 Cooling The RG-ES126FGS-LP switch adopts fan cooling design. To ensure the normal operation of the device, maintain a minimum clearance of 10 cm (3.94 in.) around the device. Dust the device every three months to avoid blocking the ventilation openings.
Page 59 Hardware Installation and Reference Guide Hardware Description 2. Front Panel Figure 1-36 Front Panel of a RG-ES126FGS-P Switch Table 1-40 Front Panel Specifications Item Description System Status LED Off: The switch is not powered on. Solid on: The switch is powered on. PoE Status LED Solid green: PoE is enabled.
Page 60: Technical Specifications
Hardware Installation and Reference Guide Hardware Description Item Description higher. In addition, factors such as cable quality, powered device performance, and ambient temperature may cause the transmission distance to be less than 250 m (820.21 ft). Default mode: Flow control is enabled and all ports can communicate with each other.
Page 61 Hardware Installation and Reference Guide Hardware Description 24 10/100 Mbps self-adaptive Ethernet ports (supporting Auto MDI/MDIX). Ports 1-24 support PoE power supply. Service Ports One 10/100/1000 Mbps self-adaptive Ethernet port (supporting Auto MDI/MDIX) One 10/100/1000 Mbps combo port AC input: Rated voltage range: 100 V AC to 240 V AC Power Supply Maximum voltage range: 90 V AC to 264 V AC...
Page 62: Cooling
Hardware Installation and Reference Guide Hardware Description Ground Leakage ≤ 3.5 mA Current Dimensions 440 mm x 214.9 mm x 44 mm(17.32 in. x 8.46 in. x 1.73 in.) (W x D x H) Weight 3.7 kg (8.16 lbs, with packaging materials) Warning ...
Page 63: Getting Started
Hardware Installation and Reference Guide Getting Started Getting Started Preparing for Installation 2.1.1 Safety Precautions Note  To avoid device damage and physical injury, please read the safety precautions carefully before installing the device.  The following safety precautions may not cover all possible dangers. 1.
Page 64: Installation Environment Requirements
Hardware Installation and Reference Guide Getting Started in case of accidents.  Check the device carefully before shutting down the power supply.  Select a correct leakage protector (also referred to as “leakage current switch” or “leakage current breaker”) for the power supply system. When there is a risk of leakage and electric shock, the power supply is automatically disconnected.
Page 65 Hardware Installation and Reference Guide Getting Started 2. Ventilation Requirements Maintain a proper clearance around the device for air circulation and normal heat dissipation. After various cables are connected, bundle the cables or place them in the cable management bracket to avoid blocking air inlets.
Page 66 Hardware Installation and Reference Guide Getting Started Apart from dust, the salt, acid, and sulfide in the air in the server room must meet strict requirements. These harmful substances will accelerate metal corrosion and component aging. Therefore, the equipment room should be properly protected against the intrusion of harmful gases, such as sulfur dioxide, hydrogen sulfide, nitrogen dioxide, and chlorine gas.
Page 67: Rack Installation Requirements
Hardware Installation and Reference Guide Getting Started Grounding required for electromagnetic compatibility (EMC) includes shielded grounding, filter grounding, noise and interference suppression, and level reference, which contribute to the overall grounding requirements. The grounding resistance should be less than 1 ohm, and the grounding lugs of the cabinet should be grounded before the running of the device.
Page 68: Tools
Hardware Installation and Reference Guide Getting Started Figure 2-1 A Standard 19-inch Rack (3) The distance between the square hole strip on the rack column and the outer side of the front cabinet door is greater than 180 mm (7.09 in.) and the thickness of the front cabinet door is less than 25 mm (0.98 in.). Therefore, the available space is greater than 155 mm (6.10 in.).
Page 69: Installing The Switch
Hardware Installation and Reference Guide Getting Started Installing the Switch 2.2.1 RG-ES05F/RG-ES05G-L...
Page 70: Rg-Es08F/Rg-Es08G-L
Hardware Installation and Reference Guide Getting Started 2.2.2 RG-ES08F/RG-ES08G-L...
Page 71: Rg-Es106F-P
Hardware Installation and Reference Guide Getting Started 2.2.3 RG-ES106F-P...
Page 72: Rg-Es110Fg-P
Hardware Installation and Reference Guide Getting Started 2.2.4 RG-ES110FG-P...
Page 73: Rg-Es110F-P
Hardware Installation and Reference Guide Getting Started 2.2.5 RG-ES110F-P...
Page 74: Rg-Es110Gs-P-L
Hardware Installation and Reference Guide Getting Started 2.2.6 RG-ES110GS-P-L...
Page 75: Rg-Es116G-L
Hardware Installation and Reference Guide Getting Started 2.2.7 RG-ES116G-L...
Page 76: Rg-Es118Fgs-Lp
Hardware Installation and Reference Guide Getting Started 2.2.8 RG-ES118FGS-LP...
Page 77 Hardware Installation and Reference Guide Getting Started...
Page 78: Rg-Es118Gs-P-L
Hardware Installation and Reference Guide Getting Started 2.2.9 RG-ES118GS-P-L...
Page 79 Hardware Installation and Reference Guide Getting Started...
Page 80: Rg-Es124G-L
Hardware Installation and Reference Guide Getting Started 2.2.10 RG-ES124G-L...
Page 81: Rg-Es126Fgs-Lp
Hardware Installation and Reference Guide Getting Started 2.2.11 RG-ES126FGS-LP...
Page 82 Hardware Installation and Reference Guide Getting Started...
Page 83: Rg-Es126Fgs-P
Hardware Installation and Reference Guide Getting Started 2.2.12 RG-ES126FGS-P...
Page 84: Checklist Before Power-On
Hardware Installation and Reference Guide Getting Started 2.2.13 Checklist before Power-on  Check whether the switch is properly grounded.  Check whether the switch is properly installed in the rack.  Check whether the power cord is properly connected.  Check whether the power supply voltage meets the requirements.
