  • Page 1 PROTEUS RAYZOR 1960 User Manual...
  • Page 2 ©2022 ELATION PROFESSIONAL all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ELATION PROFES- SIONAL logo and identifying product names and numbers herein are trademarks of ELATION PROFESSIONAL. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.

  • Page 3: Table Of Contents

    TA B L E O F C O N T E N T S Introduction Warranty Returns Safety Precautions Maintenance Guidelines Overview Installation Torque Settings for Screws Remote Device Management (RDM) Control Panel System Menu Record Controller Fan Control and Low Noise Operation Lighting Console Patching Guidelines DMX Traits FX Generator Guidelines...

  • Page 4: Introduction

    (5). BOX CONTENTS Power Cable (x1) CUSTOMER SUPPORT Contact ELATION Service for any product related service and support needs. Also visit forums.elationlighting.com with questions, comments or suggestions. ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST 323-582-3322 | Fax 323-832-9142 | support@elationlighting.com...
  • Page 5 I N T R O D U C T I O N LENS POSITION FOR SHIPPING AND PACKAGING: When re-packaging this fixture for shipping or transportation, the device must be placed securely into the form-fitting foam in-lay (FIL) that was included in the box when the fixture was first purchased.

  • Page 6: Warranty Returns

    (included and/or optional) are shipped with the product, ELATION and/ or the ELATION Authorized Service Center shall have no liability what so ever for the loss and/or damage to any such accessories, nor the safe return thereof. If the requested war-...

  • Page 7: Safety Precautions

    This fixture is a sophisticated piece of electronic equipment. To guarantee a smooth opera- tion, it is important to follow all instructions and guidelines in this manual. Elation Profes- sional is not responsible for injuries and/or damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual.
  • Page 8 S A F E T Y P R E C A U T I O N S • DO NOT TOUCH the fixture housing during operation. Turn OFF the power and allow ap- proximately 15 minutes for the fixture to cool down before servicing. •...

  • Page 9: Maintenance Guidelines

    Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture. Please refer all other service issues to an autho- rized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.
  • Page 10 Refer to the illustration below to the right. 3. Replace and tighten screw cap to secure the battery in place. NOTE: Replace the battery only with an Li-ion battery (IRC14500/700mAh), which can be ordered from the Elation Parts Website. https://parts.elationlighting.com/catalog/product/view/id/18373/s/60420050026/cat- egory/2/...

  • Page 11: Overview

    O V E R V I E W Lens Tilt Lock Mode/Esc Button Lock Button Carrying Handle Display Left Enter Right Down Button Button Screen Button Button Battery Compartment Power RJ45 RJ45 Valve Input Input Output Input Output...

  • Page 12: Installation

    I N S TA L L AT I O N FLAMMABLE MATERIAL WARNING Keep fixture minimum 3.3 feet (1.0m) away from flammable materials and/or pyro- technics. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installa- tions.
  • Page 13 I N S TA L L AT I O N G U I D E L I N E S OMEGA BRACKET INSTALLATION When mounting the fixture to a truss using Omega brackets, first attach a mounting clamp to each Omega bracket using an M10 screw inserted through the center hole of each Omega bracket (see top illustration).
  • Page 14 I N S TA L L AT I O N G U I D E L I N E S CLAMP INSTALLATION Alternately, the fixture can be mounted to a truss using mounting clamps secured directly to the fixture itself. Insert one minimum grade 8.8 steel M12x25mm bolts (not included) into the mounting hole of each mounting clamp.
  • Page 15 I N S TA L L AT I O N G U I D E L I N E S RIGGING Overhead rigging requires extensive experience, including calculating working load limits, installation material being used, and periodic safety inspection of all installation mate- rial and the fixture, among other skills.
  • Page 16 I N S TA L L AT I O N G U I D E L I N E S ART-NET AND sACN CONNECTION When connecting the fixture to a network switch to control multiple devices, a Gigabit Ethernet Switch that supports IGMP (Internet Group Management Protocol) is required. Using a Gigabit Ethernet Switch that does not support IGMP can cause erratic behavior of all connected devices to the switch.
  • Page 17 LEDs. This issue is not specific only to Elation lighting fixtures, but rather it is a common issue with lighting fixtures from all manufacturers. Although there is no true way to fully prevent this issue from happening, the guidelines below can reduce the risk of potential damage.
  • Page 18 I N S TA L L AT I O N SUN PROTECTION MODE This fixture incorporates an automatic protection from harmful sun rays, which can damage the fixture’s internal components as a result of extended exposure. The fixture uses an inter- nal sensor to determine physical orientation, then point the fixture towards the ground to prevent sunlight from entering the lens.
  • Page 19 I N S TA L L AT I O N HIBERNATION MODE This mode disables motors and most electronics in order to reduce wear on the fixture’s inter- nal components. The user has the ability the define the period of time that the fixture can remain inactive before it enters hibernation mode.

  • Page 20: Torque Settings For Screws

    T O R Q U E S E T T I N G S F O R S C R E W S PANEL SCREWS MUST BE TIGHTENED WITH A TORQUE WRENCH. REFER TO THE TABLE AND DIAGRAM BELOW FOR PROPER TORQUE SETTINGS. ITEM NO.
  • Page 21 CAUTION! DO NOT OVER TORQUE SCREWS AS THIS CAN CAUSE LEAKAGE ISSUES! TO CONFIRM THE IP65 INTEGRITY AFTER A LAMP REPLACEMENT, TEST THE FIXTURE USING THE IP TESTER. CONTACT ELATION SERVICE FOR MORE DETAILS. CAUTION! THE USE OF PROTECTIVE GLOVES AND SAFETY GOGGLES IS...

  • Page 22: Remote Device Management (Rdm)

    R E M O T E D E V I C E M A N A G E M E N T ( R D M ) NOTE: In order for RDM to work properly, RDM enabled equipment must be used through- out the entire system, including DMX data splitters and wireless systems.

  • Page 23: Control Panel

    C O N T R O L P A N E L This fixture features an easy to navigate system menu. The control panel located on the front of the fixture (see image below) provides access to the main system menu and is where all necessary system adjustments are made to the fixture.

  • Page 24: System Menu

    S Y S T E M M E N U ELATION PROTEUS RAYZOR 1960 SYSTEM MENU Supports Software Versions: 2.0.0 Features subject to change without notice. Rotation direction (clockwise/counter-clockwise) and control of effects depend on head orientation and pan/tilt settings.
  • Page 25 S Y S T E M M E N U ELATION PROTEUS RAYZOR 1960 SYSTEM MENU MAIN MENU SUB MENU OPTIONS / VALUES DESCRIPTION Feedback On / Off Movement Feedback Status Settings (continued) Hibernation Off, 01min - 99min Default = 15min...
  • Page 26 S Y S T E M M E N U ELATION PROTEUS RAYZOR 1960 SYSTEM MENU MAIN MENU SUB MENU OPTIONS / VALUES DESCRIPTION Reset All RESET Reset Pan & Tilt FUNCTION Reset Others Test Channel Pan... Pan = xxx...

  • Page 27: Record Controller

    R E C O R D C O N T R O L L E R The fixture features an integrated DMX recorder that can be used to transmit the pro- grammed scenes from your DMX controller to the moving head. Adjust the desired scene num- bers via the encoder (from –...
  • Page 28 R E C O R D C O N T R O L L E R EXAMPLE: WORKING WITH BUILT-IN PROGRAMS Program 2 includes scenes: 10, 11, 12, & 13 Program 4 includes scenes: 8, 9, & 10 Program 6 includes scenes: 12, 13, 14, & 15 Auto Pro Part 1 is Program 2 Auto Pro Part 2 is Program 3 Auto Pro Part 3 is Program 6...

  • Page 29: Fan Control And Low Noise Operation

    F A N C O N T R O L A N D L O W N O I S E O P E R AT I O N The Proteus Rayzor 1960 is a high-performance fixture suited for multiple applications. For noise critical environments such as Theater, Opera, or Orchestral Halls, it offers various fan operation modes which remove unwanted noise distractions for the audience and performers.

  • Page 30: Lighting Console Patching Guidelines

    L I G H T I N G C O N S O L E P AT C H I N G G U I D E L I N E S The PROTEUS RAYZOR 1960 is a versatile luminaire which combines two fixtures into one housing, allowing it to produce multiple unique lighting effects typically not found in a single lighting fixture.
  • Page 31 L I G H T I N G C O N S O L E P AT C H I N G G U I D E L I N E S CATEGORY GROUP PIXELS Column 1 Column 2 4, 13 Column 3 1, 9, 17 Column 4...
  • Page 32 L I G H T I N G C O N S O L E P AT C H I N G G U I D E L I N E S There are also two additional parts for a primary control of the PROTEUS RAYZOR 1960, which creates four separate control areas for the fixture.
  • Page 33 L I G H T I N G C O N S O L E P AT C H I N G G U I D E L I N E S ONYX screen shots below illustrate Main and Sub Fixture ID patch for a single PROTEUS RAYZOR 1960 fixture.
  • Page 34 L I G H T I N G C O N S O L E P AT C H I N G G U I D E L I N E S ONYX groups example below for easier selection of a single PROTEUS RAYZOR 1960 fixture.

  • Page 35: Dmx Traits

    D M X T R A I T S ELATION PROTEUS RAYZOR 1960 DMX Channel Traits Supports Software Versions: 2.0.0 Features subject to change without notice. Rotation direction (clockwise/counter-clockwise) and control of effects depends on head orientation and pan/tilt settings.
  • Page 36 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Color Wheel (continued) 050 - 054 Teal 055 - 059 Cyan 060 - 064 Light Blue 065 - 069 Aqua 070 - 074 Dark Aqua 075 - 079 Green Blue 080 - 084 Light Lavender 085 - 089 Dark Purple...
  • Page 37 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Strobe 000 - 031 Shutter Closed 032 - 063 Shutter Open 064 - 095 Strobe, slow to fast 096 - 127 Fast Close, Slow Open Snap 128 - 159 Fast Open, Slow Close 160 - 191 Pulse Effects...
  • Page 38 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Zoom 000 - 245 Zoom, wide to narrow Fade 246 - 255 Overdrive, minimum to maximum 000 - 255 Zoom Fine Fade Pan/Tilt Speed 000 - 225 Speed, maximum to minimum...
  • Page 39 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Refresh (Hz) (continued) 1030 1040 1050 1060 1070 1080 1090 1100 1110 1120 1130 1140 1150 1160 1170 1180 1190 1200 1210 1220 Snap...
  • Page 40 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Refresh (Hz) (continued) 1430 1440 1450 1460 1470 1480 1490 1500 2500 4000 5000 6000 10000 15000 20000 Snap 25000 169 - 192 Idle 193 - 194 Hibernate Off 195 - 196 Hibernate On 197 - 198 Sun Protection On...
  • Page 41 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED Spark LED FX Speed 000 - 126 Reverse, fast to slow Fade 127 - 128 Stop 129 - 255 Forward, slow to fast FX Offset Idle Fixture Offset, 10 degrees to 350...
  • Page 42 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED 000 - 255 Red 8, 0% to 100% Fade 000 - 255 Green 8, 0% to 100% Fade 000 - 255 Blue 8, 0% to 100% Fade 000 - 255 White 8, 0% to 100% Fade...
  • Page 43 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED 000 - 255 Green 18, 0% to 100% Fade 000 - 255 Blue 18, 0% to 100% Fade 000 - 255 White 18, 0% to 100% Fade 000 - 255 Red 19, 0% to 100% Fade...
  • Page 44 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED 000 - 255 Spark LED Dimmer 23, 0% to 100% Fade 000 - 255 Spark LED Dimmer 24, 0% to 100% Fade 000 - 255 Spark LED Dimmer 25, 0% to 100% Fade...
  • Page 45 D M X T R A I T S CHANNEL FADE DEFAULT FUNCTION VALUES STATUS VALUE STANDARD PIXELS EXTENDED 000 - 255 Spark LED Dimmer 64, 0% to 100% Fade 000 - 255 Spark LED Dimmer 65, 0% to 100% Fade 000 - 255 Spark LED Dimmer 66, 0% to 100% Fade...

  • Page 46: Fx Generator Guidelines

    F X G E N E R AT O R G U I D E L I N E S Selection and control of the integrated FX on the Proteus RAyzor 1960 is found in the Main Fixture section. All FX are available, even in the DMX control modes with the lowest channel count.

  • Page 47: Rgbw Pixel Fx Table

    R G B W P I X E L F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Sinewave - Cross In and out fade start at the same time (default) In fade completes, then out fade com- Sinewave - Full pletes Sawtooth - Cross...
  • Page 48 R G B W P I X E L F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES 8+9+10+11+12, 13+10+7, Reverse, Stop, Rotating Bar 17+14+10+6+3, 2+10+18, Forward 1+5+10+15+19, 4+10+16 Reverse, Stop, Ring 1 Chase One pixel at a time in RGBW ring 1 Forward Reverse, Stop, Ring 2 Chase...
  • Page 49 R G B W P I X E L F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Row 1 Disabled Row 2 Disabled Row 3 Disabled Row 4 Disabled Row 5 Disabled Column 1 Disabled Column 2 Disabled...
  • Page 50 R G B W P I X E L F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Color Wheel Reverse, Stop, Every column randomly selects a color Columns Forward from the color wheel on each step Reverse, Stop, A single row randomly selects R, G, B or RGBW Single Row...
  • Page 51 R G B W P I X E L F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Reverse, Stop, Blue at full flashes once over the cur- Blue Flash Forward rently mixed color on all cells Selected color wheel color at full Reverse, Stop, Color Wheel Flash...

  • Page 52: Spark Led Fx Table

    S P A R K L E D F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Sinewave - Cross In and out fade start at the same time (default) In fade complete, then out fade com- Sinewave - Full pletes Sawtooth - Cross...
  • Page 53 S P A R K L E D F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Reverse, Stop, Within each RGBW pixel, one Spark LED Pixel Ring Chase 2 Forward illuminates in ring order in each step Turns on all Spark LEDs in lens 10, then Reverse, Stop, Center Out...
  • Page 54 S P A R K L E D F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT NOTES Reverse, Stop, >< 1+5+10+14+17, 3+6+10+15+19 Forward Reverse, Stop, 8, 4+9+13, 1+5+10+14+17, >> Forward 2+6+11+15+18, 3+7+12+16+19 Reverse, Stop, 12, 7+11+16, 3+6+10+15+19, <<...
  • Page 55 S P A R K L E D F X TA B L E FX TYPE SLOT FX NAME FX ADJUSTMENT FUNCTION Lens Column 6 Disabled All Spark LEDs in RGBW column 6 Lens Column 7 Disabled All Spark LEDs in RGBW column 7 Lens Column 8 Disabled All Spark LEDs in RGBW column 8...

  • Page 56: Waveforms

    W AV E F O R M S Sinewave Step Sawtooth Ramp Up Ramp Down...

  • Page 57: Dimmer Curves

    D I M M E R C U R V E S DIMMER 100% Time (ms) 0 Sec Rise Time Down Time 0 sec Fade Time 1 sec Fade Time Dimming Curve Ramp Effect Rise Time (ms) Down Time (ms) Rise Time (ms) Down Time (ms) Standard (default)

  • Page 58: Color Temperature Table

    C O L O R T E M P E R AT U R E TA B L E COLOR TEMPERATURE (K) DMX VALUE COLOR TEMPERATURE (K) DMX VALUE 2000 4150 2050 4200 2100 4250 2150 4300 2200 4350 2250 4400 2300 4450...
  • Page 59 C O L O R T E M P E R AT U R E TA B L E COLOR TEMPERATURE (K) DMX VALUE COLOR TEMPERATURE (K) DMX VALUE 6300 8450 6350 8500 6400 8550 6450 8600 6500 8650 6550 8700 6600 8750...

  • Page 60: Primary-Secondary Set Up

    P R I M A R Y- S E C O N D A R Y S E T U P This function allows you to link units together to run in a Primary-Secondary set-up, in which one unit will act as the controlling unit and the others will react to the controlling unit’s built-in programs.

  • Page 61: Error Codes

    E R R O R C O D E S When the unit is powered on, it will automatically enter a “Reset/Test” mode, which brings all the internal motors to a home position. If an internal problem with one or more of the motors is detected, an error code will flash in the display in the form of “XXer”...

  • Page 62: Software Update

    PLEASE CONTACT ELATION SERVICE FOR FURTHER INFORMATION. An Elation E-Loader III can be used to update the fixture to the latest software. Please visit the E-Loader III product page at the Elation web site and download the product manual for step by step instructions.

  • Page 63: Dimensional Drawings

    D I M E N S I O N A L D R A W I N G S FIXTURE 9.49in 18.85in (478.72mm) (241.00mm) 5.31in 15.00in (381.09mm) (134.90mm) 18.41in (467.68mm) 14.81in (376.26mm) 7.09in (180.00mm) Drawings not shown to scale.
  • Page 64 D I M E N S I O N A L D R A W I N G S FOAM IN-LAY 21.1in (535.0mm) 19.1in (484.3mm) 18.5in (470.0mm) 4.9in (125.0mm) 14.2in (360.2mm) ϴ 0.8in (20.0mm) Drawings not shown to scale.

  • Page 65: Specifications

    S P E C I F I C AT I O N S SOURCE (19) 60W Osram RGBW LEDs (76) 2W White SparkLED™ 50,000 Hour Average LED Life* *Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

  • Page 66: Fcc Statement

    F C C S TAT E M E N T This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation.
