Appendix A - Technical Specifications
Appendix A
EMV Contactless Level 1 Version 3.0
MasterCard TQM
MCL v3.1.3, payWave v2.2, Expresspay 4.0.2, D-PAS Terminal Payment Application v1.0, D-PAS
Terminal Application Specification Bulletins CL TAS-002 v1.1, CL TAS-003 v1.0, CL TAS-004 v1.0
PCI PTS POI v6.0 SCR
TDEA (3DES)-CBC using DUKPT
FCC Part 15 Low Power Transceiver, RX verified per FCC Title 47 Part 15 Subclass C
UL/CSA/IEC 62368-1, 2nd edition
CE Certified
CE Safety: IEC 62368-1: 2014
Canada ISED Certified
AS/NZS CISPR 32 (2013), AS/NZS 4268 Table 1, Row 59 DTS 2400-2483MHz SRD (802.11), and
AS/NZS 4268 (2017) Table 1, Row 43 13.553-13.567MHz (contactless reader)
RoHS Compliant the Electrical and Electronic Equipment (EEE) Reduction of Hazardous Substances
(RoHS) European Directive 2002/95/EC
California Proposition 65 (California)
IPC-A-610 Class II Assembly
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specifications 1.1, 2.0
AES, SHA-256
Dimensions (L x W x H):
DynaProx| EMV Contactless/NFC Card Reader | Installation and Operation Manual
Technical Specifications
DynaProx Products Technical Specifications
Reference Standards and Certifications
Physical Characteristics
2.09 in. x 2.52 in. x .72 in. (53mm x 64mm x18.5mm)
