4 - Installation

4.3.3 How to Connect DynaProx to a Host via RS-232

The RS232 interface on DynaProx will a provide a UART interface at RS232 signal levels. No flow
control is provided. The signals provided are on J1 of DynaProx and are listed below.
DynaProx
PIN/WIRE SIGNAL
1 5V
2 5V
3 TXD
4 RXD
5 GND
6 GND

4.3.3.1 RS232 Cable

The RS232 cable will be customer dependent. A sample cable can be provided that has the mating
connector for DynaProx and color-coded wires. See MagTek part number: 1000008345
DynaProx| EMV Contactless/NFC Card Reader | Installation and Operation Manual
comment
output of DynaProx
input to DynaProx
Page 28 of 57 (D998200490-11)
