Specifications - Flo CoRe+ MAX Installation Manual

8. Specifications

Specification
Description of the charger
Output connector
Input connector
Maximum output power
Operating temperature range
Built-in protection
Enclosure
Shipping weight
Communication protocols
Security standard certification
Description
Level 2, 80 A charging station equipped with
display and card reader
Output connector: J1772-compliant
Split Phase 120/240 VAC supply or single
phase 120/208 VAC (refer to Figure 1 and
Figure 2)
Maximum configurable output power: 19.2
kW @ 240V or 16.64 kW @ 208V
Operating temperature range: -40 °C to 50
°C (-40 °F to 122 °F)
Overvoltage conditions and leakage current
to ground
3R-type enclosure; suitable for outdoor use
Approximately 12.15 kg (27 lbs.)
OCPP version 1.6J
EMI compliance: USA - FCC 47 CFR part 15
class A CAN - ICES-003 (A)
CSA- C22.2 No. 280 / UL 2594, CSA C22.2 No.
281.1 and 281.2 / UL 2231-1 and 2231-2
