Flo CoRe+ MAX Installation Manual page 6

CAUTION
Always use a manual screwdriver. DO NOT use an impact driver for the
screws at any time. This will void the warranty.
CAUTION
To reduce the risk of fire, only connect to a circuit equipped with
appropriate branch circuit overcurrent protection (see the
Position Table
Electrical Code (CSA C22.1-12)
(ANSI/NFPA 70).
1. Handle packaging with care. Always use safety glasses and gloves when unpacking
and installing the device.
2. Contact a certified contractor, a certified electrician, or a trained installer to ensure
compliance with local building codes, regulations, security standards, and weather
conditions.
3. Verify with local authorities that the location where the EVSE is to be installed is free
from underground pipelines or electrical equipment; otherwise, you might inflict
serious injuries on yourself and others.
4. This EVSE is designed to be wall-mounted or pedestal-mounted.
5. If installed on a wall mount configuration, do not install on or over a combustible
surface.
6. Ensure that the types of mounting surfaces of the wall and the posts are strong
enough to support more than 56.7 kg (125 lbs.) per anchoring point in the vertical and
horizontal direction.
7. Make sure that the anchors are compatible with the type of mounting surface.
8. This product must be connected to a grounded, metal, permanent wiring system.
When this is not possible, an equipment grounding conductor must be run with the
circuit conductors and connected to the equipment grounding terminal and installed
by a certified electrician.
9. Altering any part of the EVSE will automatically void the warranty.
section 1.3.1.
in ) in accordance with the
and the
Rotary
Canadian
National Electrical Code
