2. Using a flat-head screwdriver, gently rotate the switch to the desired position. Refer
to the following table to determine the rotary position:
Rotary Position
0
1
2
3
4
5
6
7
8
9
3. Detach the corresponding maximum current setting label sticker from the label set
kit that comes with the unit. Stick it over the existing label on the charging station
enclosure to inform the maintenance personnel of the maximum current setting.
Proof of installation will be required to complete the commissioning to ensure that
the label corresponds to the installation. This is important for safety and warranty
validity considerations.
Charging Station Current (A)
80
72
64
59
56
48
40
32
24
16
Current
sticker
