3. Installation Instructions

The CoRe+ MAX can be mounted on a wall or pedestal. Depending on the installation, the
power cables can be connected in three different ways (see
mounted on a CoRe+ MAX pedestal, please refer to the
Guide
for the pedestal installation procedure prior to the CoRe+ MAX installation.
Dimensions and Nominal Installation Location
3.1.
190.5 mm
[7.5"]
476.2 mm
[18.75"]
1219.2 mm
292.1 mm
1333.5 mm
[52.5"]
[48"]
FLOOR
sections 3.2 to 3.4).
CoRe+ MAX Pedestal Installation
Back side: 2 matching holes and a
rectangular cable opening when
pedestal is mounted
[11.5
95.2 mm
139.7 mm
[3.75"]
[5.5"]
1106 mm
[43.5"]
If
48.3 mm
[1.9"] 330.2 mm
[13"]
1308.1 mm
[51.5"]
977.9 mm
[38.5"]
