Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
IMPORTANT! The vehicle battery must be in good condition and fully charged for successful
1
programming. A battery charger may be connected during programming if necessary.
The harnesses must be connected in this exact order:
a) Connect the 14-pin.
b) Connect the 12-pin.
c) Connect the 10-pin.
2
When the LED turns on solid red, proceed with the next step.
Note: To skip the transponder programming and use convenience features only, press the
programming button 5 times. When the LED turns ON solid orange, proceed to step 2.
Press on the Push-to-Start (PTS) button twice (2) to turn the ignition ON. The LED flashes
orange quickly for approximately 5 seconds, then flashes green. It may flash green for 25
seconds.
3
Note: If the LED flashes red 3 or 4 times after the initial 25 seconds, wait an extra 30
seconds.
If the transponder programming was skipped, the LED turns ON solid orange for 3 seconds
then shuts OFF once the module is successfully programmed without transponder.
If the LED starts flashing orange slowly, follow the Key2GO programming below.
-
Key2GO programming:
Press the PTS button once (1) more to turn ignition OFF, remove the module from the
vehicle, and reconnect it to your computer. The web site will automatically recognize
that you are moving onto the second phase of the programming sequence. Proceed to
4
step 7.
- If the LED turns ON solid green for 3 seconds then shuts OFF, follow the Standard
programming below.
Standard programming:
Press the PTS button once (1) more to turn the ignition OFF. Proceed to step 9.
5
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid green for
3 seconds, then shuts OFF.
6
If however, the LED returns to flashing orange slowly, perform a soft reset on the module.
When the LED turns solid red, start the vehicle. The LED will turn ON solid green for 3
seconds then shuts off.
You have successfully completed the module programming sequence.
13
403.HONDA9 2.03 2014 Acura RLX (Smart Key)
