Directed DIRECTECHS DB3 Installation Manual

2013 volkswagen jetta
Hide thumbs Also See for DIRECTECHS DB3:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2013 Volkswagen Jetta
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Fuel level/EV battery level
Ignition Status
RAP Shut Down (Retained ACC Power)
Remote Start Ready
SmartStart
Tach / RPM Output
Trunk / Hatch Release
Universal RF Bypass- Key Req'd
403.VW10
v2.01
2013 Volkswagen Jetta

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTECHS DB3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed DIRECTECHS DB3

Summary of Contents for Directed DIRECTECHS DB3

  • Page 1 403.VW10 v2.01 2013 Volkswagen Jetta Functions compatible with the 2013 Volkswagen Jetta *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer Entry Monitoring Hood Pin Arm Factory Security Entry Monitoring Trunk/Hatch Pin Brake Status (foot brake) Fuel level/EV battery level Control of aftermarket alarm with OEM remote...

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Wiring diagram Immobilizer interface with OEM immobilizer receiver Locating components in the vehicle Vehicle connections Module programming Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming Feature and option list Limited one year consumer warranty Quick Reference Guide (customer copy)

  • Page 3: Introduction

    DB3 is an all-in-one door lock and override module. Warning! This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 4: Pre-Installation And Application Warnings

    [4] Starter, diodes, and brake: Starter connection is mandatory. Diodes and brake connections are only required on vehicles where brake needs to be depressed to start. [5] Locks and trunk release output: Only required if door locks or trunk are not supported in data. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 5: Wiring Diagram

    (MUX) Door lock: Red/White or Blue/Red, pin 24 Red/Yellow, pin 68 (-) Trunk Release: Violet, pin 23 (+) Brake: Black/Red, pin 43 Connector Connector Parking Light Switch (black conn. at light switch) 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 6: Immobilizer Interface With Oem Immobilizer Receiver

    NO Relay 2: Brown/Red: 12 N/A: Green, pin 6 N/A: Violet, pin 5 (-) Ground: Black, pin 4 N/A: Pink, pin 3 (-) GWR: Blue, pin 2 (+)12V : Red, pin 1 (+)12V 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
  • Page 7 - Make 4-6 loops and place them around the front of the plastic body of the vehicle’s coded key as shown above. - Test and secure mounted loops before reassembling the vehicle. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 8: Locating Components In The Vehicle

    Locating components in the vehicle 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 9: Vehicle Connections

    VESCM under driver dash, black 73 pin plug, pin 24 Blue/Red (driver door key lock) (MUX) Door Lock/Unlock Output H2/10 Yellow/Black No Connection No Connection H2/11 Orange/Black No Connection No Connection 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
  • Page 10 D2D 4-pin white connector (H4) Module Conn./Pin Color Description H4/1 Green H4/2 Black H4/3 Blue H4/4 RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 No Connection H5/2 No Connection 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
  • Page 11 Starter [4] - Must use a diode Ignition Switch, black 10 pin plug, pin 4 Red/Black Tachometer [2] Fuel Injector 1, 2 pin plug, pin 2 Violet/Brown (2.0L); Red/Black (2.5L, TDI) 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 12: Module Programming

    Press unlock on the OEM fob, then insert the key into the key switch and turn the ignition on. The LED will flash green. Wait for LED to turn solid green for 3 seconds, then off. Turn the ignition off. You have successfully completed the module programming sequence. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 13: Connecting The Module

    4-pin D2D harness. (12-pin) (D2D) (10-pin) (14-pin) W2W installation If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin harness to the module. (12-pin) (10-pin) (14-pin) 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 14: Led Diagnostics And Troubleshooting

    5 times to skip this step. Flashes red x 11 BCM programming. Failed to program the BCM. Check if doors are unlocked. If so, unlock them to solve the problem. Flashes red x 12 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
  • Page 15 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 16: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the LED starts & to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Solid Release 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 17: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 18: Feature And Option List

    Smart OEM Alarm Control will behave like a standard Safelock feature on a remote starter. It will unlock at the 2. Safelock beginning of the sequence, and relock after start and shutdown. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 19: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.

  • Page 20: Quick Reference Guide (Customer Copy)

    Press & hold for 1 second to remote start. * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
  • Page 21 Notes 403.VW10 2.01 2013 Volkswagen Jetta ©2023 Directed. All rights reserved.
