Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in pricing
accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
IMPORTANT: DO NOT turn vehicle Ignition ON with ANY vehicle connectors disconnected, including during module programming.
Š
Failure to do so may result with errors in the instrument cluster or hidden error messages.
Š Key2GO may be required if the interface does not program using the traditional method. Refer to "Module programming" for more
information.
Š All connectors are displayed from the wire side (unless specified otherwise).
Power liftgate and sliding door controls are ONLY available when the engine is OFF (where applicable).
Š
Š It is possible to get a "Keyless Starting Error" message when remote started. It will disappear when it will be started with the key.
Š Refer to "Vehicle connections" following the wiring diagram.
General notes: This section highlights important information for this specific firmware.
The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or if NOT
[1]
supported in data.
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[2]
The steering lock connection is ONLY required if the connector is present in the vehicle.
[3]
The PTS wire is mandatory in vehicles equipped with a manual transmission; otherwise it is ONLY required for PitStop/Idle mode
[4]
shutdown.
When using an external relay, use a 1N4002 diode or larger. Directed Part No. 8616 Mini Relays must be used for this connection. Refer
[5]
to the "8616 wire and color reference" on the installation diagram.
5
403.HONDA9 2.03 2014 Acura RLX (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Keys
Keys required
1
required for
for operation
programming
0
