9. Printable Data
Commands
INPUT OFF is the default, so
you must issue the command
INPUT ON before using LAYOUT
RUN.
Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
Select a Layout
Before any variable data can be transmitted to a preprogrammed
layout, the layout must be selected by means of a LAYOUT RUN
command.
LAYOUT RUN "<layout name>"
<layout name>
Example:
LAYOUT RUN "Shipping Label"
Transmit Variable Data to a Layout
After having selecting a layout using a LAYOUT RUN command,
you can transmit the variable data to their respective layout fields:
• The transmission starts with a start-of-text separator.
• Then comes a block of data to the field containing VAR1$.
• A field separator separates the blocks of data.
• Next block goes to the field containing VAR2$.
• A field separator separates the blocks of data and so on.
• The last block must also end with a field separator.
• The end of transmission is indicated by an End-of text separator.
By default, the following separators should be used:
• Start separator:
• Field separator:
• End separator:
All separators can be changed by means of INPUT ON/OFF and a
FORMAT INPUT command, see chapter 6.5.
<STX> <Input data to VAR1$> <CR> <Input data to VAR2$> <CR>.....<EOT>
Input data must not be enclosed by double quotation marks.
Example:
INPUT ON
LAYOUT RUN "Shipping Label"
<STX> Abcdefg <CR>123456789 <CR> <EOT>
Chapter 4
the name given to the layout in the LAYOUT
INPUT command and must be enclosed by
double quotation marks.
(ASCII 02 dec)
STX
(ASCII 13 dec)
CR
(ASCII 04 dec)
EOT
Label Design
33
