Intermec EasyCoder 301 Programmer's Manual page 22

3. Text Field,
cont'd.
NORIMAGE
INVIMAGE
Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
Set Font Magnification
Fonts can be magnified 1 - 4 times independently with regard to
height and width by means of a MAG command.
MAG <height mag>,<width mag>
<height mag>
<width mag>
Default:
Reset to default by: PRINTFEED|PF
Specifying both a font height and two magnification parameters
allows the user to control both the height and the aspect ratio of
printed characters. For example, to specify Swiss 721 Roman at 12
points with double width, use:
FONT "Swiss 721 BT",12,0
MAG 1,2
To specify Swiss 721 Roman at 12 points with a height:width ratio
of 2:3, use:
FONT "Swiss 721 BT",6,0
MAG 2,3
Select Normal/Inverse Printing
Normally, text is printed in black without any background (NOR-
IMAGE). Using INVIMAGE, the printing can be inversed so that
the paper gives the colour of the characters, whereas the background
will be black. The size of the background is decided by the font size
and slant. A NORIMAGE statement is only needed when changing
back from INVIMAGE printing.
NORIMAGE | NI
INVIMAGE | II
Default:
Reset to default by: PRINTFEED|PF
Chapter 4
the magnification factor 1,2,3 or 4 times with
regard to height.
the magnification factor 1,2,3 or 4 times with
regard to width.
1,1
NORIMAGE
Label Design
21
