2. General
Formatting
Commands,
cont'd.
Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
Alignment
Once the insertion point is specified, you must also decide which
part of the object should match the insertion point. For example, a
text field forms a rectangle. There are 8 anchor points along the
borders and one in the centre, numbered 1–9 as shown in this illus-
tration. The desired anchor point is specified by means of the ALIGN
command.
ALIGN | AN <anchor point>
<anchor point>
Default value:
Reset to default by: PRINTFEED|PF
Example:
AN 1
ALIGN|AN will place the lower left corner of the text field at the
insertion point specified by PRPOS. Refer to the illustration below
for detailed information on the anchor points for various types of
printable objects.
Chapter 4
is a number from 1 – 9
1
Label Design
17
