4. Bar Code Field,
cont'd.
Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
Set Bar Code Magnification
The magnification of the bar code and the bar code ratio decides the
actual thickness of the bars. For example, if BARRATIO is 3:1 and
BARMAG is 2, then the wide bars will be 6 dots thick (3 2) and the
narrow bars will be 2 dots (1 2). Magnification also affects inter-
pretations that are integrated in the code, e.g. EAN and UPC codes.
BARMAG | BM <magnification>
<magnification>
Default:
Reset to default by: PRINTFEED|PF
Bar Codes (combined command)
The BARSET command is primarily intended for complex 2-di-
mensional codes (see chapter 9.1), but can also be used to specify
more simple bar codes by means of a single command:
BARSET"<code name>",<ratio wide bars>,<ratio narrow bars>,<magn.>,<height>
<code name>
<ratio wide bars>
<ratio narrow bars> specifies ratio wide/narrow bars
<magnification>
<height>
Reset to default by: PRINTFEED|PF
Chapter 4
the enlargement factor of the bar code pat-
tern.
2
specifies bar code name
(default "INT2OF5")
specifies ratio wide/narrow bars
(default 3)
(default 1)
specifies magnification
(default 2)
specifies height of bars in dots
(default 100)
Label Design
25
