7.7 Push handles

The push handles make pushing the wheelchair easier for the attendant.
Some of the push handle designs allow the height to be adjusted to suit the needs of the attendant.

7.7.1 Adjusting the push handles

If the "height-adjustable push handle" option is used, the push handles can be adjusted in order to make pushing
easier for the attendant.
1) Release the clamping lever.
2) Adjust the height of the push handle.
3) Lock the clamping lever securely.
→ Both push handles must be adjusted to the same height.

7.8 Drive wheels

WARNING
Improper assembly of removable wheels
Tipping, falling over of the user due to wheels coming off
► After each assembly, verify the proper fit of the removable wheels. The quick-release axles must be firmly
locked in the wheel attachment.
WARNING
Defective tyres
Accidents/falling due to poor traction, reduced braking force or lack of manoeuvrability
► Maintain sufficient tyre pressure. Note the information in the section "Technical data" or on the tyre sidewall.
► Ensure that the pressure is the same in both tyres.
► Ensure that the tyres have sufficient tread depth.
CAUTION
Reaching into exposed drive parts
Crushing, pinching due to incorrect handling
► Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the product.
► Do not reach into the spokes of the rotating drive wheel while riding in the product.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
► Wear wheelchair gloves when travelling at high speeds.
The wheelchair is moved, steered, braked and stopped with the help of the handrims on the drive wheels.
To make transport easier, drive wheels with quick-release axle can be taken off the wheelchair.
