8
Install spool holder and gantry cover
Material rack *1
Material pipe and
nut *1
2020 profile cover *2
Hexagon socket flat round
head screw M4x6 *2
T nuts *2
M4x6
Step: Put flat round head M4x6 and T nuts into the material rack (as showed), place the spool holder on
the rack and fix on the profile with screws (as showed); Then place the 2020 profile cover on both side.
15
Install it on the left
Connect the filament tube
