3D Printer User Manual
3D打印机使用说明书
Aquila C2
Note: Each printer is tested before leaving factory. It is normal if there are some
residues in extruder or some tiny scratches on the build plate. It won't affect the
printing quality.
注：每台 3D 打印机在出厂前都经过打印测试，若设备喷头内存在耗材残留或打印平台有
轻微划痕，都属正常现象，不影响使用。
V1.2.1-20210731

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquila C2 and is the answer not in the manual?

Questions and answers

Related Manuals for Voxelab Aquila C2

Summary of Contents for Voxelab Aquila C2

  • Page 1 3D Printer User Manual 3D打印机使用说明书 Aquila C2 Note: Each printer is tested before leaving factory. It is normal if there are some residues in extruder or some tiny scratches on the build plate. It won’t affect the printing quality. 注：每台 3D 打印机在出厂前都经过打印测试，若设备喷头内存在耗材残留或打印平台有...

  • Page 2: Assembly Guide

    Thank you for choosing Voxelab products. For your convenience, please read the manual carefully before using it. Operate the printer accordingly. 使用须知 Voxelab team is always at your service; contact us at any time if you need Product Introduction any assistance.
  • Page 3 Notes 使用须知 Do not make any modifications to the printer. To avoid personal injury or property damage please ensure your operation followed by the Guide. Dress properly. Do not wear loose clothing or jewelry. Keeping your hair, clothing and gloves away from moving parts. Do not directly touch the nozzle and build plate to avoid high-temperature burn.

  • Page 4: Product Introduction

    Product Introduction 设备简介 XE-axis kit XE轴组件 X-axis tensioner X轴张紧器 Y-axis limit sensor Y轴限位传感器 X-axis limit sensor X轴限位传感器 Power switch and socket 电源开关及插座 Y-axis motor Y轴电机 Build plate 打印平台 Screen 显示屏 E-axis motor E轴电机 Y-axis tensioner Y轴张紧器 Knob switch 旋钮开关 X-axis motor X轴电机...

  • Page 5: Equipment Parameters

    Equipment Parameters 设备参数 Model | 型号 Voxelab Aquila C2 Print size | 成型尺寸 220*220*250 mm Forming technology | 成型技术 Number of nozzle | 喷头数量 Layer thickness | 层厚 0.05 mm - 0.4 mm Nozzle diameter | 喷嘴直径 Standard | 标配 0.4 mm XY axis precision | 精度...

  • Page 6: Spare Parts

    Spare Parts 零部件清单 Power supply Printer base *1 Screen kit *1 kit *1 Extruder kit *1 Z-axis passive block *1 底座组件 *1 显示屏组件 *1 电源组件 *1 挤出组件 *1 Z轴被动块 *1 X-axis tensioner *1 Z-axis motor kit *1 X-axis limit sensor kit *1 XE-axis kit *1 X轴张紧器...
  • Page 7 Spare Parts 零部件清单 Material pipe and 2020 profile cover *2 Synchronous belt *1 Material rack *1 nut *1 2020 型材盖 *2 同步带 *1 料架*1 料架及料架筒 *1 Remove tool *1 Cable tie *1 Storage card and Needle *1 card reader *1 金属铲刀*1 扎带...
  • Page 8 Installation of Z-axis limit sensor kit and Z-axis profiles 安装Z轴限位传感器和Z轴型材 Installation video can be found on Voxelab Youtube channel Printer base *1 底座组件 *1 Z-axis profile (left) *1 Z轴型材 (左) *1 Z-axis profile (right) *1 Z轴型材 (右) *1 M5x45 Hexagon socket head spring...
  • Page 9 Install Z-axis motor kit, T-shaped screw rod and power supply kit 安装Z轴电机组件，T型丝杆和电源组件 Step 1: Lock the T-shaped screw rod on the Z-axis motor kit, and then use two hexagon socket T-shaped screw rod *1 s M4x20 to countersunk head screw T型丝杆...
  • Page 10 Install pneumatic joint and XE-axis kit 安装气管接头和XE轴组件 X-axis profile X轴型材 Tighten the M6 Pneumatic joint by using open-end wrench. And fix the XE-axis kit with two M5x14 screws. 使用开口扳手拧紧M6气管接头；用2颗M5x14螺钉将XE轴组件固定在X轴型材上。 XE-axis kit *1 X-axis profile *1 XE轴组件 *1 X轴型材 *1 M6 Pneumatic joint *1 Hexagon socket button M6 气管接头...
  • Page 11 Install synchronous belt, extruder kit and Z-axis passive block 安装同步带，喷头组件和Z轴被动块 Put the synchronous belt into the profile along the V-wheel of the extruder kit (The belt is on the top of the profile and under the V-wheel when pushing extruder kit into the middle). 将同步带放入X轴型材凹槽中，挤出组件沿着V轮推进X轴型材（当把挤出组件推至X轴型材中间时，同步带在X轴型...
  • Page 12 Install X-axis tensioner 安装X轴张紧器 1. Disassemble the X-axis tensioner. 将X轴张紧器拆分为三个部分。 X-axis tensioner *1 X轴张紧器 *1 X-axis limit sensor kit *1 X轴限位传感器 *1 2. Insert the synchronous belt into the tensioner block. 将同步带一头穿过张紧轮。 M5x14 Hexagon socket button head screws M5x14 *2 内六角平圆头螺钉M5x14 *2 3.
  • Page 13 Install X-axis tensioner 安装X轴张紧器 4. Insert the synchronous belt buckle into the sheet metal slot at the back of the extruder and tighten X-axis tensioner completely. 将同步带两端卡入喷头组件背部的卡槽中，调节张紧轮组件的塑料旋钮直至 同步带达到合适的张紧度。 5. Lock the X-axis limit sensor kit on the XE-axis kit with two M4x8 screws. 用2颗M4x8螺丝将X轴限位传感器固定在XE轴组件上。...
  • Page 14 Install the X-axis moving kit and adjust the tightness of X-axis and Y-axis tensioners 安装X轴移动组件，调整X轴与Y轴的张紧器 ！ Back 背面 Take the fifth step: assembled components Tips: Manually rotate the X-axis and Y-axis 第5步装好的组件 tensioners to the appropriate tightness. Reference standard: Press the synchronous belt to feel its tension.
  • Page 15 Install the gantry profile and screen kit 安装顶部型材和屏幕组件 M5x25 M5x25 1. Fix the profile on the upper end of the gantry with four M5x25 screws. 用4颗M5x25螺钉将顶部型材安装在两侧Z轴型材的上方。 Gantry profile *1 顶部型材 *1 Note: Make the counterbores within the profile and face upwards. Four cap screws are slotted in the counterbores, please tighten the screws down to the profile edge.
  • Page 16 Install spool holder and profile cover 安装料架和型材盖 Install it on the left 安装在左侧 Material rack *1 料架 *1 Material pipe and nut *1 M4x6 料架筒和螺母 *1 T nuts 2020 profile cover *2 Connect the filament tube T型螺母 2020 型材盖 *2 连接导丝管...

  • Page 17: Wire Connection

    Wire connection 设备接线 1. Connect the yellow-labeled cable with "E" on 6 pin (4 wires) port to E-axis motor. 将6针（4线）端口上带有黄色标签丝印“E”的线与E轴电机连接。 2. Connect the yellow-labeled cable with "X" on 3 pin (2 wires) port to X-axis limit sensor. 将3针（2线）端口上带有黄色标签丝印“X”的线与X轴限位传感器连接。 3. Connect the yellow-labeled cable with "X" on 6 pin (4 wires) port to X-axis motor. 将6针（4线）端口上带有黄色标签丝印“X”的线与X轴电机连接。...
  • Page 18 Level Leveling operation video can be found on Voxelab Youtube channel 调平 Check the steadiness of the build plate before leveling. If the build plate is unsteady, please use open-end wrench to adjust the V-wheel to steady it. 调平平台前请确认一下平台有无晃动；若有，请使用开口扳手调节一下左右两侧v型 轮松紧度，使得平台滑动顺畅且无晃动。...
  • Page 19 Level 调平 1. Move the nozzle to the top of the leveling nut. Screw the nut and adjust the distance between the nozzle and the printing platform to about 0.1 mm (Thickness of a piece of A4 paper). 2. We can use a piece of A4 paper to assist in leveling, so that the nozzle only scratches on the A4 paper. Adjust the four leveling nuts in turn until you feel slight resistance from the nozzle when pulling the A4 paper.
  • Page 20 Preheat Note: The UI information is only for reference, the actual UI may be different. 预热 注意：界面仅供参考，实际以UI为准。 Method 1 方法 1 Press knob, select [Temperature] - [Preheat PLA/ABS]. 按压旋钮，选中【Temperature】-【Preheat PLA/ABS】。 Method 2 方法 2 Press knob, select [Temperature] - [Nozzle], rotate the knob to adjust the nozzle temperature. 按压旋钮，选中【Temperature】-【Nozzle】，旋转旋钮可调节喷嘴的温度。...

  • Page 21: Load The Filament

    Load the filament 装料 Insert filament into this position 将耗材从该位置穿过 1. When waiting for preheating, please hang the filaments on the material rack. 1. 在等待温度上升时，将耗材挂在料架上。 2. Press the handle to let filaments pass through (Loose the spring and pull filament back and forth to see if extrusion pressure is too high or too low;...
  • Page 22 Load the filament 装料 The methods of replacing filament: 1. Select [Unload Filament], waiting for the filament unload completed, pull filament out from the feeding assembly; repeat the load process. 2. To replace filament during the printing process, rotate the knob to slow the printing speed to 10% and cut off the filament nearby the feeding assembly. Insert the new filament into the filament tube, adjust the printing speed to 100%, and resume printing.

  • Page 23: Start Printing

    Start printing 开始打印 1. Ensure that the build plate has been leveled before printing. 2. Ensure that the filament has been loaded in an appropriate approach. 3. Please clean extruder before printing (Load the filament for a while to extrude all the melted filament printed last time). 4.
  • Page 24 Start printing 开始打印 Note: Do not unplug the screen cable during printing. 打印过程中请勿插拔显示屏。 Print 打印 Note: Notice the distance between the nozzle and the build plate during printing the first layer. If the distance is improper, please press knob, and select [Tune] - [Babystep Z] to perform the Z-axis offset.

  • Page 25: Mainboard Information

    Mainboard Information 主板信息 X-axis motor port Y-axis motor port Z-axis motor port Extrusion motor port TF card slot X轴电机接口 Y轴电机接口 Z轴电机接口 进丝电机接口 TF卡槽 Micro USB port Micro USB接口 Screen port 显示屏接口 Z-axis limit sensor port Power port Z轴限位传感器接口 主板电源 Mainboard Y-axis limit cooling fan sensor port...
  • Page 26 Printing Notice ！ 打印注意事项 The adhesion of glass build plate may decrease after long time using. Please apply proper amount of glue to keep and improve the adhesion. Warping issues may occur when print ABS filament in cold environment, you may use glue to enhance the adhesion. It's not recommended to print ABS filament at extremely low temperature environment, as print will fail when printed model getting away from the build plate.

  • Page 27: Troubleshooting

    Trouble Shooting 故障检修 Q： What if the screen turns dark? 黑屏或显示不良怎么办？ A： 1. Please check whether the wire of screen has those questions: loose, plugged in Q： How to upgrade the firmwares? reverse, plugged in wrong position, tilted plugging; 固件如何升级？ 2.
  • Page 28 Trouble Shooting 故障检修 Q： What if offset occurs on the printed model? 模型打印偏移怎么办？ Q： What if the files on the TF card cannot be identified? A：1. Check the tightness of the synchronous belt and ensure it is correctly installed; TF卡中文件无法识别？ 2.
  • Page 29 售后服务登记表 Please fill in this form carefully, cut out this form and mail it back to Voxelab together with the printer, or download this form from www.voxelab3dp.com, fill in this form and mail it to support@voxelab3dp.com. After-sales service shall not be provided without this form.
  • Page 30 Voxelab grants all end-users a 12-month limited warranty for all Voxelab 3D printers (except the Voxelab extruder) and a 3-month warranty for Voxelab FFF Extruder. If Voxelab 3D printer fails during normal and proper use within the warranty period (judged by Voxelab engineers), Voxelab will provide users with free maintenance services or remote after-sales support.
  • Page 31 售后服务卡 <SAC20200804> Voxelab采用谁销售谁服务的原则，如您的3D打印机是在非Voxelab官方平台购买，请向您购买的商家获取相关支持。 1. Voxelab所有3D打印机均为用户提供12个月整机有限质保。其中FFF技术3D打印机的喷头质保时间为3个月。 2. 质保期内若设备出现非人为损坏（由Voxelab工程师评定），您将获得免费配件及售后技术支持。 3. 售后服务周期以产品出厂日期为起始。如能提供清晰的发票，则以发票开具日期为起始。 4. 维修零配件可能为非全新配件，但甲方保证配件功能完全正常。维修配件质保时间与其整机质保时间相同。 以下配件不列入质保范围 以下情况不在质保范围内 · 无法提供有效质保卡或序列号（遗失、涂改、模糊无法确认）； 平台贴纸 打印平台 · 整机及部件已经超过质保有效期； 平台金属板 金属铲刀 · 设备曾经在未经Voxelab授权的维修店维修； 平台玻璃 内六角扳手 · 设备在非产品规定的工作环境下使用而造成的设备故障或损坏； U盘、TF卡及读卡器 开口扳手 · 设备正常磨损、老化或因操作造成的外观划痕或瑕疵； USB线 工具配件 · 由于使用非Voxelab指定的软件而造成的设备故障或损坏； 打印耗材 丝盘轴 · 由于使用其它品牌部件造成的设备故障或损坏； · 由于私自对设备进行改装而造成的设备故障或损坏；...
  • Page 32 Physical objects and final images might be distinct from the user manual due to differences between printer models. Voxelab reserves final explanation rights. 因每款机型不同，实物可能有所差异，请以实物为准。本说明书最终解释归浙江闪铸三维科技有限公司所有。 Official Website 天猫旗舰店 优酷自频道 Official Website: www.voxelab3dp.com E-mail: support@voxelab3dp.com Address: Xianyuan Road NO.518, Wucheng District, Jinhua, Zhejiang, China.
