V2.2.0 20210420
Quick Start Guide
WARNING
This guide is only applicable to Voxelab Proxima 8.9 3D printer
1.
Please put on gloves while using photopolymer resin to avoid
direct contact with the skin.
2.
To ensure the printing quality, please don't open the light shield
unless it's necessary.
3.
Unused photopolymer resin needs to be stored in a dark, dry,
and cool place.
4.
Please clean the finished model with anhydrous alcohol.
5.
Please install the build plate correctly, without dust and items, to
avoid damage to the LCD screen.
Proxima 8.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proxima 8.9 and is the answer not in the manual?

Questions and answers

Related Manuals for Voxelab Proxima 8.9

Summary of Contents for Voxelab Proxima 8.9

  • Page 1 Unused photopolymer resin needs to be stored in a dark, dry, and cool place. Please clean the finished model with anhydrous alcohol. Please install the build plate correctly, without dust and items, to avoid damage to the LCD screen. This guide is only applicable to Voxelab Proxima 8.9 3D printer...
  • Page 2 Dear User: Thank you for choosing and using the Voxelab products. Thank you for your support and help to Voxelab Technology.The Voxelab products have excellent quality and performance. For your convenience, please read this guide carefully before use and follow the guide strictly.
  • Page 3 Electrical Requirements Always use the device with a properly grounded outlet. Do not refit device plug. Do not use Proxima 8.9 in damp or wet environment. Do not expose Proxima 8.9 under sunshine. In case of device damage, please use the power supply provided by Voxelab.
  • Page 4 Getting To Know Your Proxima 8.9 1. Platform Tighten Knob 2. Z-axis 3. Leveller 4. Build Plate 5. Resin Box 6. Box Tighten Knob 7. LCD 8. Touched Screen 9. Ethernet 10. USB Stick Port 11. Light Shield 12. Power switch...

  • Page 5: Accessory Box

    Please clean the finished model with anhydrous alcohol. 注 意 事 项 对光敏树脂溶液进行操作时，请戴上手套，避免与皮肤直接接触。 打印时若非必须请勿打开遮光罩，避免外界光照影响打印效果。 未用完的光敏树脂溶液需放置在避光环境，保持环境阴凉通风。 模型在打印完成后可用无水乙醇（无水酒精）进行清理。 This guide is only applicable to Voxelab Polaris 3D printer 本手册仅适用于Voxelab Polaris 3D打印机 Proxima 8.9 Power Cable Power Adapter Quick Start Guide aftersales@voxelab3dp.com...
  • Page 6 Leveling Open the paper box and take out the Proxima 8.9 on the desk. Remove all protective foam and plug in the power cable. 1. Connect the power adapter and power cable. Plug the output end of the power adapter into the power input port on the back of the printer and turn on the switch.
  • Page 7 3. Install the build plate on the plate holder. 4. Tighten the platform tighten knob. 5. To loose the screws on both sides of 6. Make sure it can move free but the build plate by using an inner not to fall. hex wrench.
  • Page 8 Print Tool System Manual Residue Stop 7. Remove resin box. Put a piece of A4 paper on the 8.9’ LCD screen. Stop 8. Tap [Tool] - [Manual] and open a new window. Tap [Home] and wait for stop movement of Z-axis.
  • Page 9 Press lock the screws Press (not heavy) the top of the build plate with one hand to let four corners of build plate to touch the LCD screen evenly. ( It have to adjust the height of Z-axis If twitch a piece of A4 paper and don’t feel the large resistance. Tap [0.1mm] first and tap [↑] or [↓] in the touched screen and twitch paper and feel the resistance again.

  • Page 10: First Printing

    First Printing If bubbles are found at the top of the LCD screen, the LCD screen protective film can be removed. 1. Make sure the LCD screen, build plate and 2. Tighten the knobs to fix the box. resin box is clear enough. Install the resin box on the LCD screen.

  • Page 11: Post-Processing

    Internal Memory USB Memory Print Tool System 5. Tap the [Print] to enter the model list. Tap the model file to star the printing. Note Do not open the top cover during printing to avoid eyes hurt. Post-processing Print completed! Time: 04h57m 1.
  • Page 12 3. Remove the printed model carefully by mental scraper and put the model into the cleaning box with anhydrous alcohol to clean excess resin. Note: Do not damage the FEP film in the resin box or the LCD screen in the process of removing model.
  • Page 13 Note During installation and removal of the build plate, please be extra careful to prevent the LCD screen from damage by build plate falling down. Please observe the priting process regularly to avoid printing failure, especailly for long time printing time. Please make sure the printing environment to keep clean with less dust.

  • Page 14: Software Operation

    File(F) Edit(E) Print(P) View(V) Help(H) New Project Print Voxelab Proxima 8.9 Save Project Machine Type Load File... Save As... 3. Click the [File]- [Load File] to select the model file and click the [Printing] - [Model] to select the model.
  • Page 15 Supports Auto Supports 5. Add supports for those models that are unable to be flattened. Print I want to： Preview Print When Slice Done Voxelab Standard Grey Material Type： Save As New Remove Operation： 0.05mm Layer Height： Print More Options >>...
  • Page 16 Load the modal files 1. Copy the ‘.svgx’ file to the USB stick on the computer. It would be better to remove USB stick from computer after ‘Safely Remove USB stick ’ note to avoid file damage. Internal Memory USB Memory Print Tool System...

  • Page 17: Maintenance

    Maintenance Please keep resin box and LCD screen clear without dust and fingerprint. Do not pour the used residual resin back to the resin bottle. The waste resin can be poured into the sealing bag for sealing and then be exposed to the sun until the resin solidified.
  • Page 18 Voxelab Voxelab Voxelab Voxelab 3D Printing After-Sales Service: support@voxelab3dp.com Tel: +86 579 82238626 Web: www.voxelab3dp.com Add: 2/F, No.518, Xianyuan Road, Jinhua, Zhejiang, China...
