Congratulations on purchasing the Vektek Guardian™! The following is a step by step quick start
instruction guide to help you get the Guardian™ up and running with ease.
The Guardian™ systems includes: Fixture Transmitter P/N 33‐0110‐09, Machine Receiver P/N 33‐
0110‐08, Machine Receiver Cable and pairing tool (included with Machine Receiver). Require
Vektek Pressure Switch P/N S7‐0750‐00 (sold separately) for operation in hydraulic applications.
MACHINE RECEIVER
Step 1: Mount the Receiver to the CNC machine in a location easily viewed by the operator. Below
are dimensions for the mounting holes (Not to scale)
NOTE: The MACHINE RECEIVER is a sealed unit but not designed to be mounted
within the machine environment.
P L 3 3 0 2 R e v . P 0 8 I A W N / A
© Copyright 1986‐2010 by Vektek, Inc.
Figure 1: Guardian™ Hardware
Figure 2: MACHINE RECEIVER mounting dimensions
