Vektek Guardian™ User's guide
If the preceding chart does not correct the problem, please contact Vektek Inc at
1­800­992­0236 for additional assistance. Please have MACHINE RECEIVER
version and ID number available for technical support.
P L 3 3 0 2 R e v . P 0 8 I A W N / A
© Copyright 1986‐2010 by Vektek, Inc.
2. Machine does not
wait long enough for
Main Contact to
close.
3. Incorrect Fixture
identified
4. Main Contact not
wired correctly
5. Logic of Guardian
outputs not correct.
correct fault.
2. Allow at least 4
second for Main
Contact to close.
3. Ensure Proper
fixture has been
identified.
4. Use Diagnostics
menu to toggle Main
Contact and check
function of input to
machine.
5. The Main Contact is
Normally Closed and
all other Contacts are
Normally Open.
6. Check connection of
Relay Common.
Connect Relay
Common to the
voltage for the
proper signal, 24V
for a 24V signal and
0V for a 0V signal.
