Vektek Guardian™ User's guide
2. Use the
a. If multiple MACHINE RECEIVERS are operating, it is recommended that
3. Press ENTER to set the channel.
NOTE: The FIXTURE TRANSMITTERS can operate on any of the 15 channels.
To fix communication if a MACHINE RECEIVER channel changes:
1. Press and hold ENTER to reach the Admin Menu.
2. Press ENTER to select ADD PALLET.
a. Disregard which Pallet # the MACHINE RECEIVER displays.
3. Pass the pairing tool or other available magnet over the Guardian Logo on the
FIXTURE TRANSMITTTER.
4. The MACHINE RECEIVER will automatically exit pairing mode once the FIXTURE
TRANSMITTER has updated the channel.
Faulted Pallets
The Faulted Pallets option displays all the FIXTURE TRANSMITTERS with outstanding
faults.
To view the Faulted Pallets:
1. Press ENTER to access the Faulted Pallets option in the Admin Menu

2. Use the
a. If no FIXTURE TRANSMITTERS report a fault, the list will read "<NO FAULT
PALLETS>."
3. Press ENTER or BACK to exit to the main screen.
P L 3 3 0 2 R e v . P 0 8 I A W N / A
© Copyright 1986‐2010 by Vektek, Inc.
Figure 28: Channel Adjust Screen
 
and buttons to select the channel.
each is on a separate channel.
Figure 29: Faulted Pallets Menu

and buttons to scroll through the Faulted Pallets
P a g e | 24 of 39
