Industry Canada (IC) Compliance
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
The Guardian system MACHINE RECIEVER (P/N 33‐0110‐08) and FIXTURE TRANSMITTER (P/N
33‐0110‐09 comply with Industry Canada license‐exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
IC Machine Receiver Antenna Information
Antenna Type: Yagi
The Guardian MACHINE RECEIVER has been designed to operate with yagi antennas having a
maximum gain of 14 dB. Yagi antennas having a gain greater than 14 dB are strictly prohibited for
use with this device. The required antenna impedance is 50 ohms.
Antenna Type: Patch
The Guardian MACHINE RECEIVER has been designed to operate with patch antennas having a
maximum gain of 8 dB. Patch antennas having a gain greater than 8 dB are strictly prohibited for
use with this device. The required antenna impedance is 50 ohms.
Antenna Type: Omni­directional
The Guardian MACHINE RECEIVER has been designed to operate with omni‐directional antennas
having a maximum gain of 5 dB. Omni‐directional antennas having a gain greater than 5 dB are
strictly prohibited for use with this device. The required antenna impedance is 50 ohms.
