IMO Precision Controls K7 Series User Manual page 75

Chapter 7 Usage of Various Functions
2) Functional Specification
No. of output
Output type
Output velocity
Output pulse
Execution type of the increasing/decreasing velocity
Type of the direction designation
Load power supply
Usable range of the load power supply
Maximum load current
Initiative electric current
Maximum power dropdown under On
Electric current leakage under Off
On delayed time
Off delayed time
Remark
1) Several points can be used for the pulse output point if they are not output at the same time. Thus it is
possible that right direction pulse is output as P040, opposite direction pulse is output as P041.
Item
7-
Specification
1 point
Pulse
Max 2Kpps, Min 50pps
0 ~ 2147483647
Designation of acceleration
Right/opposite direction pulse output
DC 12V/24V
DC10.2 ~ 26.4V
150mA
Less than 0.4A, 10ms
Less than DC 0.5V
Less than 0.1mA
Less than 1ms
Less than 1ms
