Chapter 6 Input and Output Modules
6.3.2 Expansion Module
1) Specifications
Model
Specifications
Output point
Insulation method
Rated load
Voltage/current
Min. load Voltage/current
Max. load voltage/current
Current leakage when off
Max. On/off frequency
Surge Absorber
Mechanical
Life
Electrical
Off → On
Response time
On → Off
Common method
Operation indication
2) Circuit
It ' s the same with the output circuit of the base unit.
3) Output wiring
L
DC5V DC24V
REMARK
1) Refer to 7.2 ' Special Functions' for the special function units
4 points
Relay insulation
DC24V / 2A (r/load), AC220V / 2A (COS Ψ = 1) / 1 point 5A / 1COM
DC5V / 1mA
AC250V, DC110V
0.1mA (AC220V, 60Hz)
1,200/hr
None
More than 20,000,000
Rated on/off voltage/current load 100,000 or more
AC200V / 1.5A, AC240V / 1A (COSΨ = 0.7) 100,000 or more
AC200V / 1A, AC240V / 0.5A (COSΨ = 0.35) 100,000 or more
DC24V / 1A, DC100V / 0.1A (L / R = 7ms) 100,000 or more
10 ms or less
12 ms or less
1 point/ 1COM, 2 points/ 1COM
LED is on at on status of output
L L L
AC110/220V
6-１０
Expansion Module
G7E-DR10A
