IMO Precision Controls K7 Series User Manual page 119

Chapter 7 Usage of Functions
(2) Analog output characteristics
a) Voltage output
10V
5V
0V
0V 0
Input of digital amount 0 outputs analog amount 0V, 4000 does 10V. Digital input 1 equals to 2.5mV of analog amount.
b) Current output
20
10
0
0V 0
In current output, digital amount 0 exchanges to 0mA, and 4,000 does 20mA. Analog amount of digital input 1 equals to 5
.
2000 4000
Digital input value
D/A conversion characteristic (voltage output)
2000 4000
Digital input value
D/A conversion characteristic (Current output)
7- ５６
2.5
5.0025
5V
2000 2001 2002 200 200
Digital input
5
10.005
10.000
2000 2001 2002 200 200
Digital input
200
200
