Chapter 4. Names of Parts

4.2 Expansion Module

4.2.1 Digital I/O Module

4.2.2 A/D D/A Combination Module

⑤
⑥
③
4.2.3 Analog Timer Module
③
②
⑦
①
④
②
④
①
No.
① RUN LED
② Analog Input Terminal
③ Analog Input (Voltage/current) selecting jumper pin
④ Analog Output Terminal
⑤ External Power Supply Terminal (DC24V)
⑥ Expansion Cable
⑦ Expansion Cable Connecting Terminal
No.
① RUN LED
② Analog Timer Volume Control Resistance
③ Expansion Cable
④ Expansion Cable Connecting Terminal
4 -
