Chapter8 Communication Function
6) Monitor execution(Y##)
(1) Introduction
This is a function that carries out the reading of the variable registered by monitor register. This also
specifies a registered number and carries out reading of the variable registered by the number.
(2) PC request Format
Format name Header
Frame (Example) ENQ
ASCII value H05
Item
Register No. uses the same number registered during monitor register for monitor execution.
Register No.
It is possible to set from 00-09(H00-H09).
When command is lowercase(y), only one lower byte of the value resulted by adding 1 byte
BCC
each to ASCII values from ENQ to EOT is converted into ASCII, added to BCC.
(3) Response Format(ACK response)
x In case that the register Format of register No. is the Individual reading of device
Station
Format name Header
Frame (Example) ACK H10
ASCII value H06 H3130
y In case that the register Format of register No. is the continuous reading of device
Station
Format name Header
Frame (Example) ACK H10
ASCII value H06 H3130
Station No. Command
H10 Y(y)
H3130 H59(79)
Registratio Number of
Command
n No.
No.
Y(y) H09
H59(79) H3039 H3031
Registration
Command
No.
No.
Y(y) H09
H59(79) H3039
8-25
Registration No.
H09
H3039
Explanation
Number of
Data
Blocks data
H01 H04 H9183AABB
H3931383341
H3034
414242
Number of data Data
H04 H9183AABB
H3034 H3931383341414242
Tail Frame check
EOT BCC
H03
Frame
Tail
check
ETX BCC
H03
Frame
Tail
check
ETX BCC
H03
