Chapter 4. Names of Parts
No
4
Key switch mode creation
5
Dip-switch memory operation
6
RS-232C connector
7
Expansion connector cover
8
Terminal block cover
9
Private hook DIN rail
4.1.1 20-point base unit
No.
Name
1
Terminal block for power supply
2
FG circuit
3
Output terminal
4
Input terminal
5
DC24V, 24G output terminal
Name
Indicates base units drive mode
RUN: Indicates program operation
STOP: Stopped program operation
PAU / REM: usage of each modules are as follows:
See Chapter 5
9-pin DIN connector to connect with external devices like KGLWIN
Connector cover to connect with expansion unit
Protection cover for wiring of terminal block
Private part hook for DIN rail
① ②
Terminal blocks for power supply (AC 100V ~ 240V)
Frame ground
Output connecting terminal
Output connecting terminal
Service power supply for DC 24V needed place
PAUSE : temporary stopping program operation
REMOTE : Indicates remote drive
Usage
4 -
