9. Install screws, washers, and locknuts to the upright assemblies.
10. Tighten all loose hardware to 45-50 ft-lb (61-68 Nm).
11. Install bar support assemblies and bar catch assemblies to the upright assemblies.
Page 20 of 44
Item Description
1 3/4-10 x 1-1/4" Hex Head
Screw
2 3/4" Flat Washer
3 3/4"- 10 Hammer Lock Nut
Hand tighten hardware.
Qty.
20
20
20
