7. Install screws, washers, and locknuts securing the cross members to the upright assemblies.
8. Install screws, washers, spacers, and locknuts securing the pull up bars to the upright assemblies.
Page 15 of 44
Item Description
1 3/4-10 x 1-1/4" Hex Head
Screw
2 3/4" Flat Washer
3 3/4"- 10 Hammer Lock Nut
Hand tighten hardware.
Item Description
1 3/4-10 x 5" Hex Head Screw
2 3/4" Flat Washer
3 2.25 OD x 3/8" Spacer
4 3/4-10 Nylock Nut
Hand tighten hardware.
Qty.
8
8
8
Qty.
4
8
4
4
