Anchor Types; Anchor Specifications; Pullout Force; Tools Required - CYBEX Structure ST-HR Assembly Instructions Manual

Anchor Types

Anchor
Static

Anchor Specifications

Static Anchor
KH-EZ 1/4"
HUS-H 6mm

Pullout Force

Cybex specifies Hilti static and dynamic anchors. According to the anchor manufacturer, the recommended design pullout force (in
™
tension) for the specified anchors, when properly installed in cracked concrete, is provided in the side table. This table should be used
for reference only; for additional and up-to-date information on the anchor capabilities or the design pullout force in other substrates,
please consult Hilti directly at https://www.us.hilti.com.
Selected Anchor
KH-EZ ¼" x 4"
HUS-H 6MM x 120MM
KH-EZ 3/8" x 4"
KH-EZ 3/8" x 5"
HUS-H 8MM x 120MM
HUS-H 8MM x 150MM
HSL-3 M 8/40
HST M12 x 115/20
HST M12 x 195/200
KB-TZ 3/8" x 3-3/4"
* Design strength extracted from the Hilti Anchor Fastening Technology Manual issued September 2014.

Tools Required

WARNING: Adhere to manufacturer's equipment warnings and guidelines. Follow manufacturer's instructions for proper
usage.
Static Anchor
• Floor scanner / rebar detector (optional)
• 1" L-shape SDS rotary hammer
• 1/4" x 12" (6mm x 305mm) carbide drill bit (for 1/4" (6mm)
anchors)
• 3/8" x 12" (8mm x 305mm) carbide drill bit (for 3/8" (8mm)
anchors)
Subfloor between unit and concrete 0"
to 1/2" (12.7mm) thick
Imperial
Metric HUS-H 6mm x 120mm
Minimum Concrete Minimum Drill Depth in
Thickness
4-1/8" (105mm) 1/2" (12.7mm) beyond
3-3/32" (100mm) 25/64" (10mm) beyond
KH-EZ 1/4" x 4"
Minimum Concrete
Concrete
2-1/2" (63.5mm)
anchor length
2-1/64" (55mm)
anchor length
Design Resistance in Tension *
• Safety glasses
• Extension cord
• Impact wrench
• Vacuum (for debris)
Page 40 of 44
Subfloor between unit and concrete
over 1/2" (12.7mm) thick
KH-EZ 1/4" x 5"
HUS-H 6mm x 150mm
Minimum concrete
Embedment compressive strength
3000psi (20 N/mm2)
3000psi (20 N/mm2)
830 lb
3.3 kN
1535 lb
1535 lb
3.3 kN
3.3 kN
2000 lb
8 kN
8 kN
1615 lb
