Connecting the Output to a Balanced/Unbalanced
Stereo Audio Acceptor
The following are the pinouts for connecting the output to a balanced or unbalanced stereo
audio acceptor:
Figure 4: Connecting to a Balanced Stereo Audio
Acceptor
Connecting to MV-4X via RS-232
You can connect to
MV-4X
features an RS-232 3-pin terminal block connector allowing the RS-232 to control
MV-4X.
Connect an RS-232 terminal block on the rear panel of
From the RS-232 9-pin D-sub serial port connect:
•
Pin 2 to the TX pin on the
•
Pin 3 to the RX pin on the
•
Pin 5 to the G pin on the
Wiring RJ-45 Connectors
This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45 connectors.
For HDBT cables, it is recommended that the cable ground shielding be connected/soldered
to the connector shield.
EIA /TIA 568B
PIN
Wire Color
1
Orange / White
2
Orange
3
Green / White
4
Blue
5
Blue / White
6
Green
7
Brown / White
8
Brown
MV-4X – Connecting MV-4X
MV-4X
via an RS-232 connection
MV-4X
RS-232 terminal block
MV-4X
RS-232 terminal block
MV-4X
RS-232 terminal block
Figure 5: Connecting to an Unbalanced Stereo Audio
Acceptor
using, for example, a PC.
