Menu Item
Auto Layout 4
▪
Preset 1, Preset 2, Preset 3, or Preset 4 (see
on page 39).
Selecting the Window Layout Mode
MV-4X enables selecting the window layout for a specific video mode (see
Mode on page 11).
All settings are individually saved for each window and each mode.
To set the window layout mode:
1. On the front panel press MENU. The menu appears.
2. Click Window Layout.
3. Select an input:
▪
When in Matrix mode, select an input and perform the following actions:
MV-4X – Operating and Controlling MV-4X
Action
Select the preferred window
arrangement to use in Auto
mode when there are 4 active
sources.
Kramer Electronics Ltd.
Options
Quad, PoP Side or PoP Bottom
Configuring/Recalling a Preset
Setting the Video
12
