Advanced and User-friendly Operation
•
Matrix Switching – Truly seamless zero-time 4x2 switching in Matrix mode.
•
Multiple Display Options – Display any of 4 HDMI sources individually, full screen, with
seamless switching in Matrix mode. Or choose to display the sources using multi-
window modes such as fully customizable standard views like PiP (Picture in Picture)
and PoP (Picture outside of Picture) as well as Quad-window modes.
•
4 Preset Memory Locations – Supports storage of multi-window arrangements as a
preset for later use.
•
Auto Layout Support – Auto-window mode that automatically changes the number of
visible windows based on the number of live sources.
•
Independent audio source selection in all modes.
•
Image Rotation – 90, 180 and 270-degree rotation support for 4K output resolutions on
input 1 in matrix mode.
•
Selectable Border Design – Each window can have a border with a selectable color.
•
Logo Support – Upload and freely position a graphic logo overlay as well as a boot
screen logo.
•
Multi-view window Setup – Intuitive and easy adjustment of window size, position, and
settings.
•
User-friendly Control – Via the built-in Web GUI, as well via the OSD-driven front-panel
switches.
•
EDID Management – Per-input EDID management with internal or external EDID options.
•
Local Monitor View – Matrix mode is ideal for applications where the user requires a
local monitor to view the image on the display before switching it to the remote display.
Flexible Connectivity
•
4 HDMI inputs.
•
1 HDMI output and 1 HDBT output.
•
De-embedded analog balanced stereo audio output.

Typical Applications

MV-4X is ideal for these typical applications:
•
Meeting rooms - Allows users to show multiple presentations simultaneously.
•
Distance learning classrooms – Enables to show the main picture content, while the
teacher shows in the Picture-in-picture (PiP) window.
•
Medical – Quad view for operating theatres.
•
Shopping malls and residential – Shows multiple images at the same time.
•
Video editing, post production and applications that require chroma keying.
