Setting the Output Resolution Parameters
MV-4X enables setting output parameters such as the size of the image and output
resolution via the OSD MENU buttons.
OUT A and OUT B have the same resolution.
To set the output parameters:
1. On the front panel press MENU. The menu appears.
2. Click Output Resolution and define resolution
Menu Item
Resolution
The output resolution is set.
Setting OSD Parameters
MV-4X enables adjusting OSD MENU parameters.
To set the OSD parameters:
1. On the front panel press MENU. The menu appears.
2. Click OSD Settings and define the OSD parameters according to the information in the
following table:
Menu Item
Menu Position
Menu Timeout
Info. Timeout
Info. Display
Transparency
Background
Text Color
OSD parameters are set.
MV-4X – Operating and Controlling MV-4X
Function
Select the video output resolution. 1920x1080p60 is the default resolution.
Native OUT A 1280×800p60
Native OUT B 1280×960p60
480p60 1280×1024p60
576p50 1360×768p60
640×480p59 1366×768p60
800×600p60 1400×1050p60
848×480p60 1440×900p60
1024×768p60 1600×900p60RB
1280×720p50 1600×1200p60
1280×720p60 1680×1050p60
1280×768p60 1920×1080p24
Action
Set the position of the OSD menu on the
output.
Set the OSD timeout in seconds or set to
off to always display the OSD.
Set the Info. timeout in seconds or set to
off to always display the OSD.
Enable or disable the appearance of
information on the display.
Set the transparency level of the
background of the OSD menu (10 means
fully transparency).
Set the color of the background of the
OSD menu.
Set the OSD text color
Kramer Electronics Ltd.
1920×1080p25 4096x2160p30
1920×1080p30 4096x2160p50
1920×1080p50 4096x2160p59
1920×1080P60 4096x2160p60
1920×1200RB 3840×2160p50
2048×1152RB 3840×2160p59
3840×2160p24 3840×2160p60
3840×2160p25 3840×2400p60RB
3840×2160p30
4096x2160p24
4096x2160p25
Options
Top Left (default), Top Right,
Bottom Right, Bottom Left
Off (Always on), 5~60 (in 1sec
steps) (10 default)
Off (Always on), 5~60 (in 1sec
steps) (10 default)
On (default), Off
Off (default), 1~10
Black, Gray (default), Cyan
White (default), Yellow, Magenta
